Electrical Parts List
Samsung Electronics 7-1
ASSY PCB MAIN(OPT)
1 * AA94-03623C ASSY PCB MAIN(OPT);CS15K2X/BWT,KS1A,RUSS
..2 BOT AA39-00046E LEAD CONNECTOR-ASSY;,1P,JUMPER,BLK,150MM
..2 C801 2401-002213 C-AL;150uF,+30-10%,450V,GP,BK,25x35
..2 CLAMP AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 CN501 AA39-20620C LEAD CONNECTOR-ASSY;,9P,YBNH250-09,S,500
..2 IC201S AA09-00125A IC MICOM;SPM802ERN5-0333,CS2039X,64P,3.
..2 IC301 AA96-00244A ASSY H/S;-,-,AA62-00046A,LA7840,- S.N.A
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X
..2 IC601 AA96-00244D ASSY H/S;-,SOUND,AA62-00046A,TDA7266M,-
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1201-001600 IC-AUDIO AMP;7266,ZSIP,15P,-,SINGLE,26dB
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X
..2 JS701 3722-000497 JACK-PIN;4P,3.4MM,SN,BLK,-
..2 L805 AA27-10002L COIL-CHOKE;-,24UH,K,-,2A,-,24UH-K,10X10M
..2 LR401S AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5
..2 LS801S AA27-00077A COIL DEGAUSSING;-,-,4.3mH,20%,70T,9OHM,-
..2 Q401 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P,BK,8
..2 SUB-PA AA98-00079A ASSY SUB PART;KS1A,MAIN(OPT),PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
..2 T444S AA26-00065A TRANS FBT;-,FSV-14A004C(S),14-22,125V
..2 AA99-30219Y ASSY-PCB ROBOT; AA94-03623C ,ER S.N.A
...3 CR402S 2306-000350 C-FILM,MPPF;270NF,5%,400V,TP,26X18.5X10M
...3 CR410S 2301-001456 C-FILM,MPE-PPF;5.1nF,5%,1.6kV,TP,29x9x16
...3 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
...3 CY801S 2201-000446 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x
...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5.
...3 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5
...3 IC501 AA96-50311A ASSY-H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A
....4 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA
....4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
....4 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2
...3 IC801S AA96-00242A ASSY H/S;-,-,AA62-30186B,KA5Q0765R,- S.N.A
....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
....4 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M
....4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
....4 AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H
...3 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,-
....4 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI
....4 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-,
....4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
...3 IC902 1103-001106 IC-EEPROM;C81DC,1028x8Bit,DIP,8P,300MIL,
...3 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A
...3 LX801S AA29-30001D FILTER-LINE NOISE;SQ1913,-,6.0MH,0.8A,-
...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
...3 P803S 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27
...3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
...3 RM901 AA59-60001U MODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,9
...3 SF101S 2904-000302 FILTER-SAW AV;38.9MHz,SIP5K,ST,15.4dB,B/
...3 SF102S 2904-001024 FILTER-SAW AV;38.9MHz,SIP5K,TP,18.3dB,PA
...3 SW801S 3403-001107 SWITCH-PUSH;250V,5A,DPST,-,KDC-A04
...3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,7.1mH,102uH,10-20uH,
...3 T801S AA26-00104A TRANS SWITCHING;CS21S5T,AC160~250V,EER35
...3 TU01S AA40-00067A TUNER;TAEL-G671D,-,PAL,181CH,38.9MHz
...3 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,-
...3 AA99-10214B ASSY-PCB MAIN,AUTO; AA99-30219Y ,V S.N.A
....4 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5
....4 C103 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C105 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
....4 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
....4 C109 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C110 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
....4 C111 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
....4 C114 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3
....4 C115 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C119 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C120 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C121 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C203 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 C206 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C207 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C208 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C211 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C212 2401-000647 C-AL;2.2uF,20%,50V,BP,TP,5x11,5
....4 C213 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C214 2401-003102 C-AL;100uF,20%,10V,GP,TP,5x11,5
....4 C215 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm
....4 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm
....4 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
....4 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C220 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C221 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5
....4 C222 2401-000758 C-AL;220nF,20%,50V,GP,TP,5x11,5
....4 C223 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C224 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C225 2309-000138 C-FILM,PE-PPF;100nF,5%,50V,TP,20x16x8.5,
....4 C226 2202-000829 C-CERAMIC,MLC-AXIAL;.82NF,10%,50V,Y5P,TP
....4 C227 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
....4 C229 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C230 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C233 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm
....4 C234 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
....4 C248 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
....4 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
....4 C302 2201-000259 C-CERAMIC,DISC;0.18nF,10%,500V,Y5P,TP,5.
....4 C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
....4 C304 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5
....4 C305 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
....4 C306 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5
....4 C307 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm,
....4 C308 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
....4 C309 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm,
....4 C312 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
....4 C403 2401-000560 C-AL;1uF,20%,160V,GP,TP,6.3x11,5
....4 C406 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
....4 C407 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C408 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C420 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.
....4 C501 2201-000192 C-CERAMIC,DISC;0.01nF,0.25pF,500V,NP0,TP
....4 C502 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5
....4 C503 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5
....4 C504 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
....4 C505 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP
....4 C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
....4 C601 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
....4 C602 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C603 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C605 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 C606 2301-000232 C-FILM,PEF;3.3nF,5%,50V,TP,8.1x4.5x13mm,
....4 C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C703 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C704 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C705 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C706 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
7-1 CS15K2X/BWT
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
