..2 CE08 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P,TP
..2 CN702 AA39-20461C LEAD CONNECTOR-ASSY;,11P,YBNH250-11,6709
..2 CN704A AA39-00094A LEAD CONNECTOR-ASSY;,3(2)P,YBNH250-03,35
..2 JE601 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
..2 JR01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU
..2 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
..2 LE02 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
..2 LE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 LE05 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 PCB AA41-00208C PCB-FRONT AV;S4/C5 MODEL,FR-1,1L,C,1.6T, S.N.A
..2 RE01 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 RE02 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 S-MATE AA98-60001Z ASSY-SUB,PART;SCT11D,A/V FRONT,PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY-A2,BILINGUAL
1 * AA95-00977A ASSY-A2,BILINGUAL;-,20,21S4,C5,H3,15A9,K
..2 CN702 AA39-00095A LEAD CONNECTOR-ASSY;,3(2)P,YBNH250-03,35
..2 CN705 3711-002708 CONNECTOR-HEADER;NOWALL,10P,1R,2.5mm,ANG
..2 CN706 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
..2 CN707 AA39-20055A LEAD CONNECTOR-ASSY;,6P,YBNH025-06,67096
..2 ICS01 1204-001817 IC-SOUND PROCESSOR;MSP3400D-C5-G4-LH,DIP
..2 PCB AA41-00139A PCB-STEREO/LINE-ST/MTS-M;DREAM-1,1L,FR-1 S.N.A
..2 XS01 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF
..2 AA99-20091M ASSY-PCB SUB,AUTO; AA95-00977A ,V S.N.A
...3 CS01 2201-000180 C-CERAMIC,DISC;10nF,10%,50V,Y5V,TP,7x3,5
...3 CS03 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5
...3 CS06 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
...3 CS07 2201-000982 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,4
...3 CS09 2301-000111 C-FILM,PEF;1.8nF,5%,50V,TP,6.5x3.0x5.5mm
...3 CS11 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5
...3 CS12 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5
...3 CS13 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5
...3 CS14 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5
...3 CS15 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
...3 CS16 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
...3 CS17 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
...3 CS18 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
...3 CS19 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
...3 CS20 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3
...3 CS21 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
...3 CS22 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3
...3 CS23 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
...3 CS24 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
...3 CS25 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
...3 CS26 2201-000112 C-CERAMIC,DISC;1.5nF,10%,50V,Y5V,TP,5x3.
...3 CS27 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
...3 CS28 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.
...3 CS29 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
...3 CS30 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
...3 CS35 2301-000111 C-FILM,PEF;1.8nF,5%,50V,TP,6.5x3.0x5.5mm
...3 ICS02 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
...3 LS01 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
...3 LS03 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
...3 LS04 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
...3 RS01 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS04 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS06 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS07 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS08 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS09 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS14 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RS15 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
..2 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY-POWER,CORD
1 * AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY CABINET
1 * AA90-00725F ASSY CABINET;15K8,CS15K8WX/BWT S.N.A
..2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
..2 CB+CF AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S,
..2 CB+JCK 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 CRT+CF AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,-
..2 AA64-01731C CABINET BACK;15K8,HIPS,V2,BLK
..2 AA64-60385B INLAY-BACK;50.5366,LINE S/T,PS,T0.3,BLK,
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,-
..2 AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
ASSY CABINET FRONT
1 * AA91-00619B ASSY CABINET FRONT;,15K8 CIS,(SPK)S012P+ S.N.A
..2 KC+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 SPK+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 WIN+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 AA64-01371C KNOB POWER;15K8,ABS,G3676,SV012P+W971,HB
..2 AA64-01730F CABINET FRONT;15K8,S012P+B115P CIS S/T,H S.N.A
..2 AA64-70127A BADGE-BRAND;AL,FLAT,SILVER,L=40,SAMSUNG,
..2 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M S.N.A
..2 AA96-10137B ASSY-SPEAKER;-,8OHM,3W,3001-001020,AA39-
...3 3001-001020 SPEAKER;3W,8ohm,90dB,140Hz
...3 AA39-20505M LEAD CONNECTOR-ASSY;,4P,YSH025-04,REC,35
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA64-01370C KNOB CONTROL;15K8,ABS,G3676,SV012P+W971,
..2 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,-
..2 AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 AA64-00816B WINDOW REMOCON;-,21A8,-,PC,V0,VIOLET,-
..2 AA64-00818B INDICATOR LED;-,21A8,-,ACRYL,-,CLR,-
ASSY CRT
1 * AA94-02410A ASSY CRT;A36QDT351X,+380mG,15INCH,BEAR,
..2 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM
..2 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1
..2 AA27-00069A DEFLECTION-YOKE;-,DIF-1592CA,15,ST,2.0mH
..2 AA03-00146A CRT COLOR;-,A36QDT351X,+380mG,15inch,90,
ASSY ACCESSORY
1 * AA94-02746C ASSY ACCESSORY;CS15K8X/BWT,KS1A,RUSSIA S.N.A
..2 AA68-01402A MANUAL-GOOD WILL LETTER;,CIS,B5,1PAGE,A/ S.N.A
..2 AA68-01296A MANUAL USERS;-,-,RUS,-,W/P100(G),-,-,1,- S.N.A
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
..2 AA63-00239E COVER-AV;15K8,HIPS,HB,G4309,SV012P+W971
..2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-
..2 AA26-90001C TRANS-MATCHING;-,300ohm/75ohm,PAL,40-890
REMOCON
1 * AA59-00198B REMOCON;,TM59,DREAM,29,L/GRAY,STEREO,N
Electrical Parts List
7-8 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
