..2 JE601 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
..2 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
..2 PCB AA41-10903B PCB-A/V FRONT;S15A,1L,FR-1,245x245x1.6T, S.N.A
..2 RE01 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 RE02 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 RE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 S-MATE AA98-60001Z ASSY-SUB,PART;SCT11D,A/V FRONT,PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY-POWER,CORD
1 * AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY-SKD
1 * AA97-00978G ASSY-SKD;,CS2073S/BWT,KS1A,RUSSIA S.N.A
..2 CLAMP AA65-30111A CLAMP-WIRE;NYLON,V0,WHT,1T 15MM,ALL MODE S.N.A
..2 LC801S AA27-20003Y COIL-DEGAUSSING;-,20,15.2ohm,28T,L2170,E
..2 AA65-30109A CLAMP-FBT;NYLON-66,V2,BLK,-,-,- S.N.A
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- S.N.A
ASSY-CRT
1 * AA97-00415A ASSY-CRT;AA03-10029W,+380mG,A48KRD82X(H S.N.A
..2 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1
..2 AA27-50004W DEFLECTION-YOKE;-,DSE-1992LL(1H),PCL,A48
..2 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM
..2 AA03-10029W CRT-COLOR;-,A48KRD82X(H),+380mG,20,90de
ASSY CABINET FRONT
1 * AA91-00691B ASSY CABINET FRONT;DP,5073,(SPK) BK708P S.N.A
..2 KNOPOW AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 AA64-40044B WINDOW-REMOCON;-,5073,-,PC,V0,VIOLET,- S.N.A
..2 AA64-70127F BADGE-BRAND;AL,SAMSUNG,SILVER,L40,R800,N
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA96-10140A ASSY-SPEAKER;-,16ohm3W,00003,AA320501C,R
...3 3001-000003 SPEAKER;3W,16ohm,88dB,180+-36Hz
...3 AA39-20501C LEAD CONNECTOR-ASSY;,3(2)P,67096-003,REC S.N.A
..2 AA61-40007A STOPPER-PCB;5038.5368,HIPS HB,-,-,-,NTR, S.N.A
..2 AA63-50095A GRILLE-WOOFER;-,5073,PA110 PI0.6,SECC,T0
..2 AA64-00233C CABINET-FRONT;-,5073,BK708P MLN,HIPS,HB,
...3 AA61-40010A BOSS-WING;-,HIPS,-,-,-,NTR,HB
..2 AA64-10131A KNOB-POWER;-,5073,-,ABS,HB,BLK
ASSY CABINET
1 * AA90-00100F ASSY CABINET;5073,CS2073S/BWT S.N.A
..2 CB+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 CRT+CF AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,-
..2 KC+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 PA+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
..2 AA64-40182A INDICATOR-LED;-,5073,-,ACRYL,-,-,-
..2 AA64-10040A KNOB-CONTROL;DP,5073,AA64-10039A,-,-,-
...3 AA64-10039A KNOB-CONTROL;-,5073,-,ABS,HB,BLK
..2 AA64-30376N CABINET-BACK;DP,5038,64-30375D,V2,-,-,-,
...3 AA64-30375D CABINET-BACK;-,5038.73,-,HIPS,V2,BLK,-,-
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,-
..2 AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
ASSY PACKING
1 * AA92-00365C ASSY PACKING;CS2173C/NWT,KS1A S.N.A
ASSY ACCESSORY
1 * AA97-00977G ASSY ACCESSORY;,CS2073S/BWT,KS1A,RUSSIA S.N.A
..2 AA68-01296A MANUAL USERS;-,-,RUS,-,W/P100(G),-,-,1,- S.N.A
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
..2 AA63-00261B COVER-JACK;2139,HIPS,-,HB,BLK,BK708P,-
..2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-
..2 AA26-90001C TRANS-MATCHING;-,300ohm/75ohm,PAL,40-890
REMOCON
1 * AA59-00198D REMOCON;,TM59,DREAM,24,L/GRAY,MONO,NON
Electrical Parts List
7-12 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
To Next Page
