ASSY-PCB,A/V FRONT
1 * AA95-01048B ASSY-PCB,A/V FRONT;DP,20S1,KS1A,AA95-000
..2 CE06 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 CN702 AA39-20070A LEAD CONNECTOR-ASSY;,7P,YBNH025-07,67096
..2 JA702 3722-000506 JACK-RCA;2P,3.6MM,-,AG
..2 PCB AA41-10903B PCB-A/V FRONT;S15A,1L,FR-1,245x245x1.6T, S.N.A
..2 RE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 S-MATE AA98-60001Z ASSY-SUB,PART;SCT11D,A/V FRONT,PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY-SKD
1 * AA97-00978L ASSY-SKD;,CS21S1S/NWT,KS1A,UKRAINA
..2 CLAMP AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 LC801S AA27-00143A COIL DEGAUSSING;,35T,9OHM,21INCH,220V,20
..2 AA65-30111A CLAMP-WIRE;NYLON,V0,WHT,1T 15MM,ALL MODE S.N.A
..2 AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- S.N.A
ASSY CRT
1 * AA97-01085A ASSY CRT;AA03-10024T,+380mG,A51KQJ63X(H
..2 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1
..2 AA27-50005K DEFLECTION-YOKE;-,CDY-S2192M,ST-3,A51KQJ
..2 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM
..2 AA03-10024T CRT-COLOR;-,A51KQJ63X(H),+380mG,21,90de
ASSY-POWER,CORD
1 * AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY CABINET
1 * AA90-00801A ASSY CABINET;21S1,CS21S1S/NWT
..2 CB+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR S.N.A
..2 CB+RCA 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR S.N.A
..2 CRT+CF AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,-
..2 KC+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 PA+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
..2 AA64-00095E KNOB CONTROL;DP,33.50.53S1,-,-,-,AA64-10
...3 AA64-10789A KNOB-CONTROL;-,50S1,-,ABS,HB,M/BROWN
..2 AA64-00563G CABINET BACK;DP,21S1,AA64-31327B,V2
...3 AA64-31327B CABINET-BACK;-,53S1,-,HIPS,V2,BLK,-,-
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,-
..2 AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
ASSY CABINET FRONT
1 * AA91-00392C ASSY CABINET FRONT;DP,21S1 CIS,(SPK)B708
..2 KNOPOW AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 SPK+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA64-70123B BADGE-BRAND;AL,R2000,SILVER,L=50,SAMSUNG
..2 AA64-40515E DECORATION-FRONT;-,21S1,KSP213 ML TVI,HI
..2 AA64-40514A INDICATOR-LED;-,CT50S1,-,ACRYL,-,CLR,-
..2 AA96-00163B ASSY SPEAKER;-,8ohm,6W,3001-001034,350/7
...3 3001-001034 SPEAKER;6W,8ohm,90dB,140Hz
...3 AA39-20505M LEAD CONNECTOR-ASSY;,4P,YSH025-04,REC,35
..2 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,-
..2 AA63-50356A GRILLE-WOOFER;-,53S1,-,SECC,T0.5,BLK,-
..2 AA64-10790C KNOB-POWER;-,33.50S1,NO-SILK,ABS,HB,M/BR
..2 AA64-31326L CABINET FRONT;53S1,BK708P PROGUN II,HIPS
..2 AA64-40513B WINDOW-REMOCON;-,50S1,-,PC,V0,VIOLET,- S.N.A
ASSY-PACKING
1 * AA92-90001D ASSY-PACKING;S15,F3 S.N.A
ASSY ACCESSORY
1 * AA97-00977L ASSY ACCESSORY;,CS21S1S/NWT,KS1A,UKRAINE
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
..2 AA68-01010A MANUAL USERS;-,-,B5,-,W/P100(G),-,-,1,-,
..2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-
..2 AA26-90001C TRANS-MATCHING;-,300ohm/75ohm,PAL,40-890
REMOCON
1 * AA59-00198D REMOCON;,TM59,DREAM,24,L/GRAY,MONO,NON
Electrical Parts List
7-28 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
