....4 C689 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP
....4 C689 2202-000829 C-CERAMIC,MLC-AXIAL;820pF,10%,50V,Y5P,TP
....4 C689 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
....4 C2560 2301-000213 C-FILM,LEAD-PEF;220nF,5%,250V,TP,21.5x11
....4 C2560 2301-000224 C-FILM,LEAD-PEF;22nF,5%,50V,TP,7.4x3.9x1
....4 C2560 2301-000224 C-FILM,LEAD-PEF;22nF,5%,50V,TP,7.4x3.9x1
....4 C2560 2301-000254 C-FILM,LEAD-PEF;39nF,5%,50V,TP,7.5x3.5x6
....4 C2560 2301-000301 C-FILM,LEAD-PEF;6.8nF,5%,50V,TP,6.5X5.5X
....4 C2560 2301-000301 C-FILM,LEAD-PEF;6.8nF,5%,50V,TP,6.5X5.5X
....4 C2560 2301-000342 C-FILM,LEAD-PEF;2.2nF,5%,50V,TP,7.4x3.9x
....4 C2560 2301-000342 C-FILM,LEAD-PEF;2.2nF,5%,50V,TP,7.4x3.9x
....4 C2560 2301-000342 C-FILM,LEAD-PEF;2.2nF,5%,50V,TP,7.4x3.9x
....4 C2560 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
....4 C2560 2301-000445 C-FILM,LEAD-PEF;4.7nF,5%,50V,TP,5.5x7x3m
....4 C420 2301-001065 C-FILM,LEAD-PPF;47nF,5%,630V,TP,19x15.5x
....4 C2560 2305-000149 C-FILM,LEAD-PEF;100nF,5%,100V,TP,12x12.5
....4 C2560 2305-000285 C-FILM,LEAD-PEF;220NF,5%,100V,TP,10.5X5.
....4 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
....4 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
....4 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
....4 CR405S 2305-000382 C-FILM,MPEF;4.7NF,5%,400V,TP,-,5MM.
....4 C2560 2305-000412 C-FILM,LEAD-PEF;470nF,5%,63V,TP,-,5mm
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C225 2301-001664 C-FILM,MPE-PPF;100nF,3%,50V,TP,20x16x8.5
....4 C701 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5
....4 C701 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
....4 C701 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
....4 C701 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
....4 C701 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
....4 C701 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
....4 C701 2401-000055 C-AL;1uF,20%,160V,WT,TP,3x11,5mm
....4 C701 2401-000603 C-AL;1UF,20%,50V,GP,TP,5X11,2
....4 C701 2401-000603 C-AL;1UF,20%,50V,GP,TP,5X11,2
....4 C701 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5
....4 C701 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5
....4 C701 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5
....4 C701 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
....4 C701 2401-001192 C-AL;33uF,20%,50V,GP,TP,6.3x11,5
....4 C701 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
....4 C701 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
....4 C701 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5
....4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C701 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
....4 C701 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
....4 C701 2401-000050 C-AL;10uF,20%,16V,GP,TP,5x11,2.5
....4 C701 2401-000050 C-AL;10uF,20%,16V,GP,TP,5x11,2.5
....4 C701 2401-000050 C-AL;10uF,20%,16V,GP,TP,5x11,2.5
....4 C701 2401-000050 C-AL;10uF,20%,16V,GP,TP,5x11,2.5
....4 C701 2401-000050 C-AL;10uF,20%,16V,GP,TP,5x11,2.5
....4 C701 2401-002290 C-AL;47uF,20%,160V,GP,TP,13x20,5
....4 C701 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5
....4 C701 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
....4 C701 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5
....4 L103 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
....4 L202 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
....4 L903 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
....4 R101 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
....4 R102 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
....4 L203 2701-000127 INDUCTOR-AXIAL;15UH,10%,2534
....4 L301 2701-000142 INDUCTOR-AXIAL;1UH,10%,2534
....4 L302 2701-000142 INDUCTOR-AXIAL;1UH,10%,2534
....4 L404 2701-000142 INDUCTOR-AXIAL;1UH,10%,2534
....4 L102 2701-000159 INDUCTOR-AXIAL;22UH,10%,4298
....4 L201 2701-000159 INDUCTOR-AXIAL;22UH,10%,4298
....4 L230 2701-000159 INDUCTOR-AXIAL;22UH,10%,4298
....4 L405 2701-000159 INDUCTOR-AXIAL;22UH,10%,4298
....4 L902 2701-000177 INDUCTOR-AXIAL;33UH,10%,2534
....4 L904 2701-000177 INDUCTOR-AXIAL;33UH,10%,2534
....4 L804 2701-001030 INDUCTOR-AXIAL;43UH,10%,4514
....4 L807 2701-001030 INDUCTOR-AXIAL;43UH,10%,4514
....4 F101 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP,,,50
....4 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP,,,50
....4 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP,,,50
....4 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP,,,50
....4 SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 FD801S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS
....4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 02VER AA41-00625C PCB-MAIN;TXM1967X/XAA,FR-1,1L,C,1.6T,245 S.N.A
....4 EY401 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY402 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY403 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY404 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY405 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY414 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY415 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY416 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY417 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY418 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY419 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY420 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY421 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY501 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY819 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY827 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY829 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EY833 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
....4 EL401 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A
....4 EL402 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A
....4 EL801 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A
....4 EL802 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A
....4 GT501 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT801 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT802 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT803 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT804 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT805 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT101 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 GT806 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
....4 Z201 2903-000129 FILTER-CERAMIC;BR,4.5MHz,-,-,-,TP,-
....4 C701 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
....4 R505 2008-000264 R-FUSIBLE(S);1ohm,5%,1W,AF,TP,3.9x10mm
....4 R825 2008-000264 R-FUSIBLE(S);1ohm,5%,1W,AF,TP,3.9x10mm
....4 CR403S 2306-000179 C-FILM,LEAD-PPF;300nF,5%,250V,TP,20x18.5
....4 C701 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm,
....4 T0083 0402-001443 DIODE-RECTIFIER;EGP20K,800V,2A,TO-220F,T
....4 R811 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9
....4 R812 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9
....4 C701 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
....4 L2514 3301-001223 BEAD-AXIAL;62ohm,3.5x0.8x5mm,,TP,,,
....4 L2514 3301-001223 BEAD-AXIAL;62ohm,3.5x0.8x5mm,,TP,,,
....4 C2560 2301-000289 C-FILM,LEAD-PEF;5.6nF,5%,50V,TP,7x6x3,5
....4 R125 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 C701 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm,
...3 X901 2801-004033 CRYSTAL-UNIT;12MHZ,30PPM,28-AAM,30PF,30O
...3 GT301 AA60-40012D PIN-GT,ASSY;4P,T1.6,6-12.5-14MM,NYLON66 S.N.A
...3 T0066 AA96-20129C ASSY POWER CORD;-,EP2/YES,H/C200,ME301P, S.N.A
....4 T0077 AA39-10007Y CBF POWER CORD;-,EP2/YES,SPT-2 18AWGx2C,
....4 AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 S.N.A
ASSY ACCESSORY
1 M0045 AA92-08377A ASSY ACCESSORY;K15D,14/20,XAP S.N.A
7-3Samsung Electronics
Electrical Parts List
Level Loc.No. Code No. Description;Specification Remark Level Loc.No. Code No. Description;Specification Remark
