ASSY COVER FRONT
1 M0001 AA90-04320B ASSY COVER FRONT;CT20F3FX/XAX S.N.A
..2 T0081 6002-000512 SCREW-TAPPING;RH,+,2,M4,L12,ZPC(BLK),SWR S.N.A
..2 CCM1 AA60-10050R SCREW-MACHINE;-,SWRCH18A,M5,L31.5,HH,+,W S.N.A
..2 T0607 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- S.N.A
..2 T0003 AA64-03156A CABINET-FRONT;20F3(SAMEX),HIPS HB
...3 T0081 6002-000512 SCREW-TAPPING;RH,+,2,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0081 6002-000512 SCREW-TAPPING;RH,+,2,M4,L12,ZPC(BLK),SWR S.N.A
...3 CIS7 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, S.N.A
...3 T0299 AA64-03012A WINDOW-RMC,LED;14F3,PC,CLR S.N.A
...3 T0022 AA64-03007A KNOB-CONTROL;14F3,ABS,HB,G3676,SVM-3012 S.N.A
...3 T0023 AA64-03008A KNOB-POWER;14F3,ABS,HB,G3676,SVM-3012 S.N.A
..2 T0057 AA64-70126A BADGE-BRAND;ALL,AL,T1.5,7.5,L45,R2000,SI S.N.A
..2 CWIRE2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 CWFC AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A
..2 T0522 AA96-10007A ASSY SPEAKER;-,8ohm,3W,O5F14BRA,-,L300 S.N.A
...3 T0082 3001-001037 SPEAKER;5W,8OHM,89DB,180HZ
...3 T0245 AA39-20500G LEAD CONNECTOR-ASSY;,3(2)P,300MM,67096-0
ASSY COVER REAR
1 M0002 AA90-04321B ASSY COVER REAR;CT20F3FX/XAX S.N.A
..2 T0081 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A
..2 T0015 AA64-03157A CABINET-BACK;20F3(SAMEX),HIPS HB
..2 T0214 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- S.N.A
..2 H/T AA61-00356B HOLDER-TUNER,F/JACK;501F,ABS,-,-,-,BLK,H S.N.A
..2 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- S.N.A
..2 CLW/HS AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
ASSY CPT
1 T0521 AA91-06032A ASSY CPT;A48KRD82X(H)+380MG,NONAFTA,MALA S.N.A
..2 T0063 AA03-00246A CRT COLOR;A48KRD82X(H),380MG,2.20MH,30.0
..2 T0079 AA27-00002A MAGNET CONVERGENCE;JH291-SC-OB,29.1MM,-,
..2 T0078 AA27-00127A DEFLECTION YOKE;,DSE-1992LL,PCL,A48KRD82
..2 T0089 AA27-00254A COIL DEGAUSSING;,20INCH,10%,70TS,4.5OHM,
..2 CDCOIL AA61-00734A HOLDER;25POLYVINYL,DEGAUSSING,T0.5,CHLO S.N.A
..2 SPACER AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1 S.N.A
..2 A/TBC AA97-01678A ASSY TBC WIRE;,19,NTSC,1P,SAMEX S.N.A
..2 M0162 6502-001019 CABLE CLAMP;DAMC-10,ID9.9,T7.1,NYLON6.6, S.N.A
ASSY CHASSIS
1 M0017 AA91-07058A ASSY CHASSIS;K15D,20,MONO,CT20F3 S.N.A
..2 FBT AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 M0014 AA94-14124A ASSY PCB MAIN;20,MONO,K15D,F/V,LATIN
...3 0202-001366 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb, S.N.A
...3 T0090 0502-001265 TR-POWER;FJAF6810D,NPN,60000mW,TO-3PF,ST
...3 IC112 1103-001209 IC-EEPROM;24C04,512x8,DIP,8P,10.16x7.11m
...3 C598 2201-000446 C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,BK,15X
...3 CR401S 2303-001015 C-FILM,LEAD-PPF;5.5NF,5%,1.6KV,BK,29X9.5
...3 SF101S 2904-001221 FILTER-SAW AV,45.75MHz,SIP5K,ST,14.2dB,M
...3 SWN01 3404-000295 SWITCH-TACT;12VDC,50mA,160gf,8.4X22.7,SP
...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5.
...3 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,-
...3 JA701 3722-000162 JACK-PIN;2P,3.4mm,SN,BLK,-
...3 T0119 AA09-00374A IC MICOM;TDA9377PS/N2/AI,TXM1967,64P,3.3
...3 T801S AA26-00172A TRANS-SWITCHING;EER3543,K15D,90~264,PM2A
...3 T0616 AA26-00065A TRANS FBT;-,FSV-14A004C(S),14-22,125V
...3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH,
...3 LR401S AA27-00053A COIL-LINEARLITY;-,193uH,DR10X10 C:4.35,7
...3 LX801S AA29-30001D FILTER LINE NOISE;SQ1913,-,6.0MH,0.8A,-
...3 RM901 AA32-00015A MODULE-REMOCON;FRP-3521H31,38KHZ,940MM,M
...3 CN501 AA39-20620B LEAD-CONNECTOR;ASSY,9P,YBNH250-09,S,400m
...3 TU01S AA40-00073A TUNER-TECC1040PG32A(S),181CH,45.75MHZ,75
...3 IC301 AA96-00244A ASSY H/S;-,-,AA62-00046A,LA7840,- S.N.A
....4 0205-001153 GREASE-SILICON;SC102,JAPAN,- S.N.A
....4 T0088 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI
....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A
...3 IC601 AA96-00244D ASSY H/S;-,SOUND,AA62-00046A,TDA7266M,- S.N.A
....4 0205-001153 GREASE-SILICON;SC102,JAPAN,- S.N.A
....4 T0085 1201-001600 IC-AUDIO AMP;7266,ZSIP,15P,-,SINGLE,26dB
....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A
...3 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,- S.N.A
....4 IC062 1203-001939 IC-MULTI REG.;7632,SIP,10P,-,PLASTIC,3.3
....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
....4 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-, S.N.A
...3 IC501 AA96-50311A ASSY-H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A
....4 T0074 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA
....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
....4 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A
...3 IC801S AA96-00816A ASSY H/S;,POWER,AA62-00112A,5Q0765RT,TRO S.N.A
....4 0205-001153 GREASE-SILICON;SC102,JAPAN,- S.N.A
....4 T0086 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M
....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 AA62-00112A HEAT SINK;TROJAN,AL1050 ,T2.0,W54.0,H40. S.N.A
...3 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A
...3 C701 2401-002219 C-AL;220uF,20%,400V,GP,BK,25x40,10
...3 T0900 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
...3 CN906 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH
...3 P803T 1404-001265 THERMISTOR-PTC;4.5OHM/100OHM,+30/-20%,22
...3 T0245 AA39-20010H LEAD CONNECTOR-ASSY;,1P,300,YFH800-01,S,
...3 A/AUTO AA97-13358A ASSY AUTO;K15D,20,F/V,MONO,LATIN,CT20F3 S.N.A
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
....4 CISS 0401-000006 DIODE-SWITCHING;BAV21,250V,200MA,DO-35,T
....4 CISS 0401-000006 DIODE-SWITCHING;BAV21,250V,200MA,DO-35,T
....4 T0083 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 T0083 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
....4 T0083 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
....4 T0083 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
7-1Samsung Electronics
Electrical Parts List
Level Loc.No. Code No. Description;Specification Remark Level Loc.No. Code No. Description;Specification Remark
Yon can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
7. Electrical Parts List
7-1
CT20F3FNT/XAP
