Server Network Settings
MENU m → Network → Server Network Settings → ENTER E
Connect to server
Connect to MagicInfo server.
• Server Address / SSL / Port
―
If the SSL option is enabled, the server is configured to use https and data transfer is
encrypted.
―
Enter the server IP address and port number. Use 7001 as the port number. (If unable to
connect to the server using port number 7001, check with your server administrator to find
the correct port number and then change the port number.)
Server Access
Select a method to connect the server network.
• Allow / Deny
FTP Mode
Specify the FTP operating mode.
• Active / Passive
Device Name
MENU m → Network → Device Name → ENTER E
Select or enter a device name.
This name can be shown on network remote controls over the network.
• User Input / [Signage]Display 1 ~ 6
