Installation
English34
Installation
11. Place the door on the other side, and
then reattach it to the dryer.
NOTE
Insert the head of the screw on the back
of the hinge into the hole above the cut
out in the frame, and then slide the door
hinge down until it stops. Make sure the
protrusion on the back of the hinge is
pressed into the cut out before you tighten
the hinge screws.
12. Push the lever holder into the cut out
on the other side of the door opening.
Insert screws, and then tighten as
shown.
13. Re-attach the remaining screws to the
remaining holes above and below the
lever holder, and then tighten.
