31
12. Setting up a wash machine.
12-3.
Door Opening Dimension(Slim Model)
255 mm
Upper
※
Maximum door angle(
③
)is170
°
●
(When The Door Vertically Open )
The distance between door
①
and the rear side
②
is 824mm
①
●
(When the door extremely open
※
)
The distance between the door edge(
①
) and the left side of washing
machine(
②
)is255mm
②
③
824 mm
Side
①
②
225 mm
