Samsung F1015JGB/YLP - Oscillator Part PCB Check; Buzzer Part PCB Check

18
8-2-4. Checking The Part Of An Oscillator
8-2-5. Check The Part Of Buzzer
When The Micom 27,28
Check, The Value Is
8Mhz?
Check Resonator
Exchange Micom And Check R29
27
28
R29 1M
RESO
8MHz
ⓐ
Part Confirm DC12V ?
Check The Part Of Power Source
Exchange BZ,
Check R40,R13
12
R13 10K
BZ
R40 1K
IC6
12V
ⓐ
ⓑ
NO
YES
NO
YES
