15. Screw/Bolt List
CODE NO. DESCRIPTION SPECIFICATION Q'TY ASSEMBLY LOCATION
DC60-40144A BOLT-HEX M10,L41,ZPC2(YEL),SM10C/DAMPER 2 DAMPER+FRAME
6011-001232 BOLT-HEX D7,L71(39.4),ZPC(YEL),SWRCH18A 1 WEIGHT/L
6011-001422 BOLT-HEX M10,L20,ZPC(YEL),SWRCH10A 1
DC60-40140A BOLT-HEX WEIGHT-UL/SM10C,HEX,M8,L147,-,ZPC2(YEL),-,- 2 WEIGHT/U
DC60-40141A BOLT-HEX SM10C/DAMPER,HEX,M8,L66,-,ZPC2(YEL),-,- 2 DAMPER+TUB
DC60-40005A BOLT-HEX M4,L60,ZPC2(YEL),SS41C,-,-,-,- 1
DC60-50148B NUT-HEX SM20C(NYLON),M12,-,-,ZPC3(YEL),-,HEX,P-PROJECT 1 PULLEY
DC60-50153A NUT-HEX 3,M8,FZY,FE,- 1 FILTER-EMI
DC60-10019B SCREW MACHINE RH,+,M5,L12,STS430,SEAL-LOCK 2 HINGE+FRAME
DC60-10019B SCREW MACHINE RH,+,M5,L12,STS430,SEAL-LOCK 2 HOLD-GLASS+HINGE
DC60-10023A SCREW MACHINE TH,+,D4,L10,ZPC2,TAP-TITE 1 B/K-PRESSURE+FRAME
DC60-10023A SCREW MACHINE TH,+,D4,L10,ZPC2,TAP-TITE 1 B/SPRING + EARTH
DC60-20054D SCREW TAPPING TH,+,1,D4,L12,STS304,- 2 S/W-DOOR+FRAME
DC60-20054D SCREW TAPPING TH,+,1,D4,L12,STS304,- 2 COVER-DOOR
DC60-20140A SCREW TAPPING FH,+,1,D4,L20,WHT,HSWR1018 2 LEVER-DOOR
DC60-20030A SCREW TAPPING FH,-,1,D4,L12,NTR,- 1 C-PANEL+FRAME
DC60-20049A SCREW TAPPING SCM430,2,PH,+,D4,L12,-,-,-,- 5 PCB+C-PANEL
DC60-20054C SCREW TAPPING TH,+,1,D4,L12,FE FZY,- 1 CLAMP-HOSE+FRAME
DC60-20054D SCREW TAPPING TH,+,1,D4,L12,STS304,- 2 PUMP+FRAME
DC60-20060A SCREW TAPPING TH,+,2,D4,L8,FE,FZY 1 E/W(SUB)+FRAME(F)
DC60-20060A SCREW TAPPING TH,+,2,D4,L8,FE,FZY 8 FRAME+FRAME-FRONT
DC60-20060A SCREW TAPPING TH,+,2,D4,L8,FE,FZY 4 FRAME+PLATE-UPPER
DC60-20138A SCREW TAPPING PH,TORX,1,D4,L12,ZPC2,- 1 P/CORD
DC60-20060A SCREW TAPPING TH,+,2,D4,L8,FE,FZY 1
DC60-20054D SCREW TAPPING TH,+,1,D4,L12,STS304,- 1 VANE-CHECK
DC60-20049A SCREW TAPPING SCM430,2,PH,+,D4,L12,-,-,-,- 1 HOUSING-DRAWER
DC60-20054C SCREW TAPPING TH,+,1,D4,L12,FE FZY,- 1 HOUSING-DRAWER
DC60-20136A SCREW TAPPING TH,+,2,D5,20,ZPC3,COVER-TOP 2 FRAME(TOP)
DC60-20050C SCREW TAPPING -,-,2S,D3,L8,FZY,- 2 B/K+PRE-S/W
DC60-20054A SCREW TAPPING TH,+,1,D4,L10,ZPC3,- 2 B/K-C.T
DC60-20054C SCREW TAPPING TH,+,1,D4,L12,FE FZY,- 1
6001-000947 SCREW-MACHINE TH,+,M4,L10,NTR/WHT,STS304 2 W/V+FRAME
DE60-10022A SCREW-PH PH,+,M3,L8,MSWR10,FEFZY,-,-,-, 2
DC60-30015B SCREW-SPECIAL FLANGE,PH,+,D4,L12,ZnFe(YEL),- 2 SHUTTER
DC60-30015B SCREW-SPECIAL FLANGE,PH,+,D4,L12,ZnFe(YEL),- 1 TUB+HOSE-PRESS
DC60-30015B SCREW-SPECIAL FLANGE,PH,+,D4,L12,ZnFe(YEL),- 2 C/TOP+FRAME
DE60-10012A SCREW-TAP TITE TH,+,3,M4,L10,SWR10,ZPC2,TOOTH 1 H/BEARING+E/W
DE60-10012A SCREW-TAP TITE TH,+,3,M4,L10,SWR10,ZPC2,TOOTH 1 P/CORD(E/W)
6002-000161 SCREW-TAPPING PH,+,2,M4,L8,ZPC(YEL),SM20C 2 DECORATION
6002-000444 SCREW-TAPPING TH,+,2S,M4,L14,NTR,STS304 2 B/K-HEATER
6002-000445 SCREW-TAPPING TH,+,2S,M4,L18,NTR,STS304 2 PANEL+FRM+HOUSING-D
DC60-60040A WASHER-NYLON -,ID10.5,OD32,T2,-,PBSP-1/2H 1 FIXER
DC60-60025C WASHER-PLAIN PVC,ID5.5,OD10,T1,-,-,WHT(SWF-P12) 2 HINGE
DC60-60044B WASHER-PLAIN SBC,ID8.4,OD30,T3,-,-,- 1 FIXER
DC60-60044A WASHER-PLAIN -,ID10.5,OD30,T3,-,STS304 2 DAMPER+TUB
DC60-60044B WASHER-PLAIN SBC,ID8.4,OD30,T3,-,-,- 1 MOTOR
DC60-60044B WASHER-PLAIN SBC,ID8.4,OD30,T3,-,-,- 2 WEIGHT/L
DC60-60044B WASHER-PLAIN SBC,ID8.4,OD30,T3,-,-,- 2 WEIGHT/U
