Samsung Generation 6 - First Fix Notes

www.jouleuk.co.uk | www.joule.ie
18
First Fix Notes
Outdoor Unit Cable
Size
Breaker Size
HHSM-G600005-1
4.0mm 16Amp
HHSM-G600008-1
4.0mm 20Amp
HHSM-G600012-1
6.0mm 25Amp
HHSM-G600016-1
6.0mm 32 Amp
Primary Pipework From Outdoor Unit To Indoor Cylinder
• 5W – 28mm copper
• 9kW – 28mm copper
• 12kW – 28mm copper
• 16kW – 28mm copper
• Outdoor pipework should be fully insulated and protected from water and moisture.
• If outdoor pipework is required use Joule outdoor low energy loss pipework (supplied by the meter)
Electrical Supply And Cable Requirements
• Shielded 0.75mm 2 core cable from outdoor unit to cylinder / wiring centre location.
• Shielded 0.75mm 2 core cable from wiring centre to samsung controller.
• Power supply to outdoor unit to be terminated with IP67 isolator located next to the unit.
• Power supply to indoor unit (MIM board) to be terminated switch fused isolator.
Outdoor Unit Cable
Size
Breaker Size
MIM E03CN (5kW)
4.0mm 20Amp
• Power supply to the MIM units must connect
to the RCD tted inside of the MIM unit.
Cable
Size
No. of
Cores
Location
0.75mm
2 Core
Screened
From indoor unit to outdoor
unit.
F1 & F2 Comms.
0.75mm
2 Core +
Earth
From Zone 1 stat or
Underoor heating control
cen- tre to Indoor unit.
0.75mm
2 Core +
Earth
From Zone 2 stat or
Underoor heating control
cen- tre to indoor unit.
0.75mm
2 Core
Screened
From MIM unit to remote
controller.
• When installing the outdoor unit take great
care to install as per the detailed notes for
installation locations. The Air-to-Water Heat
Pump must have minimum clearance of
300mm at the rear of the unit and 1500mm
at the front of the unit.
• The Air-to-Water Heat Pump must not be in-
stalled in a location without these clearances
available.
• Condensation will form on the Air-to-Water
Heat Pump. Ensure adequate provisions
are put in place to prevent water forming on
the ground beneath the Air-to-Water Heat
Pump, resulting in a potential Health and
Safety hazard.
• The Air-to-Water Heat Pump must be in-
stalled vertically and should not be tilted at
an angle.
