20
When the air outlet is opposite the wall. When the air outlet is towards the wall.
When 3 sides of the outdoor unit are blocked
by the wall.
The upper part of the outdoor unit and the air
outlet is towards the wall.
The upper part of the outdoor unit and the air
outlet is opposite the wall.
When front and rear side of the outdoor unit is
towards the wall.
300mm or more
1500mm or more
300mm or more
600mm or more
300mm or more
600mm or more
1500mm or more
300mm or more
600mm or more
1500mm or more 300mm or more
Locating The Outdoor Unit
When Installing 1 Outdoor Unit
