5-1Samsung Electronics
Electrical Part List
5. Electrical Part List
5-1 HPS5053X/XAA Service Item
Yon can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
CIS3 BN40-00081A TUNER DNVS303HH261A,DNVS303HH261A,VS 1 S.A
M0013 BN96-03154A ASSY STAND P-BASE 42,50C7,HGI T3.0,BKP-1 1 S.A
M0013 BN96-03161A ASSY COVER P-REAR 50C7,P7,PCM T0.5 1 S.A
M0018 BN97-00755A ASSY MICOM T-CADINUS5-0061,S3F866B,20060 1 S.A
M0018 BN97-00911A ASSY MICOM T-CADINUS0U-0009,HP-S5053,D75 1 S.A
M0020 BN96-03075B ASSY BOARD P-SIDE AV CADILLAC,SJ06-01-00 1 S.A
M0145 BN96-02784B ASSY BOARD P-FUNCTION CADILLAC,SJ06-01-0 1 S.A
M2893 BN39-00477A LEAD CONNECTOR D66A/SPD-50P4HD,UL20276#3 1 S.A
M2893 BN39-00632A LEAD CONNECTOR HPR4252,UL1617#22,UL/CSA, 1 S.A
M2893 BP39-00053E LEAD CONNECTOR HP-R4252,UL1007#26,UL/CSA 1 S.A
M2893 MD39-00074G LEAD CONNECTOR V18C,UL1007#26,UL/CSA,12P 1 S.A
T0003 BN96-03126B ASSY COVER P-FRONT 50P7/Q7,SEA,ABS HB,BK 1 S.A
T0044 BN96-03290A ASSY PDP MODULE P-PDP MODULE M1,50HD,V5. 1 S.A
T0074 BN59-00511A REMOCON Bordeaux,TM87B,54,ATSC/NTSC,USA, 1 S.A
T0079 BN94-00925A ASSY PCB MISC-MAIN HP-S5053,D75A 1 S.A
T0159 BN96-01856A ASSY PCB P-SMPS SPD-50P5HD(DC_DC),200Vin 1 S.A
T0159 BN96-03051A ASSY PCB P-SMPS HPS5053,Free Voltage,245 1 S.A
T0175 BN96-03392A ASSY SPEAKER P 8ohm,Q7,10W,2Way,2speaker 1 S.A
T0253 BN59-00498A MODULE-SPLITTER UMX-NT-059,UMX-NT-059,2i 1 S.A
T1910 BN96-03359A ASSY PDP MODULE P-X MAIN BOARD 50HD,PL50 1 S.A
T1911 BN96-03360A ASSY PDP MODULE P-Y MAIN BOARD 50HD,PL50 1 S.A
T1912 BN96-03361A ASSY PDP MODULE P-Y MAIN UPPER 50HD,PL50 1 S.A
T1913 BN96-03362A ASSY PDP MODULE P-Y MAIN LOWWE 50HD,PL50 1 S.A
T1914 BN96-03363A ASSY PDP MODULE P-ADDRESS E BU 50HD,PL50 1 S.A
T1915 BN96-03364A ASSY PDP MODULE P-ADDRESS F BU 50HD,PL50 1 S.A
T1916 BN96-03365A ASSY PDP MODULE P-ADDRESS G BU 50HD,PL50 1 S.A
T1917 BN96-03366A ASSY PDP MODULE P-LOGIC MAIN B 50HD,PL50 1 S.A
