Wiring Diagram
Samsung Electronics 8-1
ASSY PCB MISC-MAIN
BN94-00925A
ASSY POWER & IR
BN96-03320A
ASSY FUNCTION
BN96-02784B
ASSY SIDE-AV
BN96-03075B
ASSY SPEAKER
BN96-03392A
※ The ASS'Y code can be changed, see "5 Chapter. Electrical Part List."
8. Wiring Diagram
8-1 Overall Wiring
