Samsung HT-C5200/EDC User Manual

5-7 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
KAR13 2007-000060 R-CHIP 100Kohm,1%,1/10W,TP,1608 3 SNA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 10 SA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 6 SNA
KOP1 1201-000163 IC-OP AMP 4560,SOP,8P,173MIL,DUAL,100V/m 2 SA
KQ1 0501-000279 TR-SMALL SIGNAL KSA1182-Y,PNP,150mW,SOT- 2 SA
KQ6 0501-000341 TR-SMALL SIGNAL KSC1623-L,NPN,200mW,SOT- 1 SA
MC111 2203-000646 C-CER,CHIP 0.024nF,5%,50V,C0G,TP,1608 2 SNA
MIC10 0801-002391 IC-CMOS LOGIC 74LCX00,NAND GATE,TSSOP,14 2 SNA
MR112 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 14 SA
MR122 2007-000094 R-CHIP 22Kohm,5%,1/10W,TP,1608 7 SA
MR19 2007-000087 R-CHIP 6.8Kohm,5%,1/10W,TP,1608 8 SA
MR2 2007-000130 R-CHIP 39Kohm,5%,1/10W,TP,1608 3 SA
MR9 2007-000127 R-CHIP 9.1Kohm,5%,1/10W,TP,1608 6 SNA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 23 SA
ND51C2 2007-000066 R-CHIP 20Kohm,1%,1/10W,TP,1608 3 SNA
P803T 1404-001483 THERMISTOR-PTC 470ohm,50%,32V,TP 2 SA
PC69 2203-006818 C-CER,CHIP 47000nF,20%,6.3V,X5R,3216 3 SA
PCW2 3711-003359 HEADER-BOARD TO CABLE BOX,10P,1R,2.5mm,S 1 SA
PPD1 0402-000309 DIODE-RECTIFIER 1SR154-400,400V,1A,SOD-1 1 SA
PR4 2007-000052 R-CHIP 10Kohm,1%,1/10W,TP,1608 3 SA
PR6 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 18 SNA
PR6 2007-000583 R-CHIP 22Kohm,1%,1/10W,TP,1608 2 SA
Q1 0501-000479 TR-SMALL SIGNAL KST42,NPN,350mW,SOT-23,T 5 SA
Q1040 0501-000457 TR-SMALL SIGNAL MMBT2222A/KST2222A,NPN,3 2 SA
Q301 0501-000481 TR-SMALL SIGNAL KST92,PNP,350mW,SOT-23,T 3 SA
Q409 0505-002365 FET-SILICON IRF6645,N,100V,5.7A,0.035ohm 6 SNA
R1 2007-002425 R-CHIP 1ohm,5%,1/10W,TP,1608 6 SNA
R15 2007-000134 R-CHIP 33Kohm,5%,1/10W,TP,1608 3 SNA
R1P151 2007-000121 R-CHIP 820ohm,5%,1/10W,TP,1608 3 SA
R1S36 2007-000491 R-CHIP 2.2Kohm,1%,1/10W,TP,1608 3 SA
R227 2007-000086 R-CHIP 5.6Kohm,5%,1/10W,TP,1608 1 SA
R319 2007-000143 R-CHIP 4.7Kohm,5%,1/16W,TP,1005 1 SNA
R419 2007-000882 R-CHIP 4.7ohm,5%,1/10W,TP,1608 2 SA
R505 2007-000496 R-CHIP 2.2Kohm,5%,1/4W,TP,3216 3 SA
R509 2007-001179 R-CHIP 8.2Kohm,5%,1/10W,TP,1608 2 SA
R510 2007-000108 R-CHIP 510Kohm,5%,1/10W,TP,1608 1 SA
R893B 2007-000122 R-CHIP 1.2Kohm,5%,1/10W,TP,1608 6 SA
RR2 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 1 SA
T0052 2703-002524 INDUCTOR-SMD 10uH,10%,3225 2 SNA
T0052 2703-003768 INDUCTOR-SMD 330uH,20%,6060 1 SNA
T0081 6001-000571 SCREW-MACHINE PH,+,-,M3,L8,ZPC(WHT),SWRC 2 SNA
T0087 1203-002835 IC-POSI.FIXED REG. KIA7805AF,DPAK,3P,6.6 1 SA
T0415 3716-001243 TERMINAL-BLOCK WIRE TYPE,12P,14mm,0V,0A 1 SA
T0568 3301-001404 BEAD-SMD 30ohm,2012,TP,15.9OHM/30MHz 4 SA
WC31 2305-000407 C-FILM,LEAD-PEF 470nF,5%,100V,TP,10.5x6x 3 SA
X202 2801-004371 CRYSTAL-SMD 12.288MHz,50ppm,SX-1,18pF,50 1 SNA
ZR24 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608 1 SA
ZVL3 3301-001495 BEAD-SMD 120ohm,2012,2500mA,TP,115ohm/10 2 SA
