Samsung Electronics 5-8
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
0103-007285 RESIN-PC BK0007,2.0 V2,PC/GF20%,Glass fi 2 SNA
0202-001463 SOLDER-WIRE LFC2-W3.0,-,D3,99.79Sn/0.2Cu 6.171 SNA
0202-001477 SOLDER-CREAM LST309-M,D20~45um,96.5Sn/3A 2.38 SNA
0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.167 SNA
0204-002420 SOLVENT 1M-1000,C3H70H,96 3.25 SNA
0204-002607 FLUX DF-234U,13%,14KG,Gravity 0.82 2.52 SNA
0403-001441 DIODE-ZENER MMSZ5239B,5%,500MW,SOD-123,T 2 SA
0403-001483 DIODE-ZENER UDZS18B,17.56-18.35V,200mW,S 2 SA
0501-000150 TR-SMALL SIGNAL 2SA1037,PNP,200mW,SOT-23 1 SA
0504-000105 TR-DIGITAL DTA114EU,PNP,200MW,10K/10K,SC 1 SA
1003-002268 IC-GATE DRIVER IRS2053MTRPBF,MLPQ,48P,7X 1 SA
1203-006105 IC-DC/DC CONVERTER MAX5033DUSA,SO,8P,4.9 1 SNA
1203-006107 IC-NEGA.FIXED REG. KIA7905F,DPAK,3P,6.6x 1 SNA
1204-002968 IC-MODULATOR PS9830B,TQFP,100P,14x14mm,P 1 SA
2007-000253 R-CHIP 1.5ohm,5%,1/4W,TP,3216 2 SA
2007-000464 R-CHIP 18ohm,5%,1/4W,TP,3216 1 SA
2007-000819 R-CHIP 390Kohm,5%,1/10W,TP,1608 1 SA
2007-001300 R-CHIP 56ohm,5%,1/2W,TP,5025 1 SNA
2007-007065 R-CHIP 10ohm,5%,1W,TP,6432 3 SA
2007-007625 R-CHIP 0ohm,5%,1W,TP,6432 1 SA
2007-007723 R-CHIP 75Kohm,1%,1/10W,TP,1608 1 SA
2007-007750 R-CHIP 39ohm,1%,1W,TP,6432 1 SNA
2301-001760 C-FILM,MPEF 100nF,10%,250V,TP,B5xH13.5x1 3 SA
AH27-00081A COIL FILTER DBF-16A18(OFC),18.2uH,30mohm 3 SNA
AH41-01302B PCB-AMP HT-C5500,FR-4,2,02,T1.6,143x158, 1 SNA
AH63-02106B SHEET-THERMAL_IC HT-C5500,GAP PAD,2T,80, 1 SNA
AH97-04331A ASSY AUTO BD HOME THEATER,5500 AMP PCB A 1 SNA
AH97-04332A ASSY SMD BD HOME THEATER,ASSY SMD 5500 A 1 SNA
AH97-04333A ASSY MANUAL INSERT HT-C5500,ASSY MANUAL 1 SNA
M0014 AH94-02433F ASSY PCB MAIN HT-C5500,BD HOME THEATER,E 1 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 12 SNA
AAC14 2203-000888 C-CER,CHIP 4.7nF,10%,50V,X7R,TP,1608 2 SA
AC109 2203-000783 C-CER,CHIP 0.33nF,5%,50V,C0G,1608 2 SA
AC510 3708-001436 CONNECTOR-FPC/FFC/PIC 4P,1mm,SMD-S,SN,N 1 SA
AC510 3708-001935 CONNECTOR-FPC/FFC/PIC 40P,0.5mm,SMD-S,AU 1 SNA
AC510 3708-001981 CONNECTOR-FPC/FFC/PIC 28P,1mm,SMD-S,SN,N 2 SNA
AC510 3708-002603 CONNECTOR-FPC/FFC/PIC 22P,1mm,SMD-S,SN,N 1 SNA
AC510 3708-002619 CONNECTOR-FPC/FFC/PIC 13P,1.0MM,SMD-S,SN 1 SNA
AD480 2203-000585 C-CER,CHIP 0.22nF,10%,50V,X7R,1005 1 SA
AD480 2203-000679 C-CER,CHIP 0.027nF,5%,50V,C0G,1005 2 SA
AD480 2203-002994 C-CER,CHIP 0.068nF,5%,50V,CH,BK,1005 4 SNA
AD480 2203-005659 C-CER,CHIP 0.18nF,5%,50V,NP0,1005 1 SNA
AD480 2203-006336 C-CER,CHIP 10000nF,10%,25V,X5R,3216 11 SA
AD480 2203-006824 C-CER,CHIP 4700nF,10%,10V,X5R,1608 8 SNA
AHR41 2007-001175 R-CHIP 8.2Kohm,1%,1/10W,TP,1608 1 SA
AIC2 1002-001558 IC-A/D CONVERTER AK5367,24,VSOP,30P,9.7x 1 SA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 2 SA
AR108 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 1 SA
