Samsung HT-C5200/EDC User Manual

5-9 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
AR161 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 7 SNA
AR28 2007-000683 R-CHIP 3.3Kohm,1%,1/10W,TP,1608 1 SA
AR30 2007-001306 R-CHIP 150ohm,5%,1/16W,TP,1005 1 SA
AR48 2007-000431 R-CHIP 16Kohm,5%,1/10W,TP,1608 2 SA
AR49 2007-000140 R-CHIP 1Kohm,5%,1/16W,TP,1005 33 SNA
AR61 2007-000869 R-CHIP 4.7Kohm,1%,1/10W,TP,1608 1 SA
AS503 AH63-02117B SHEET-LENS SWA-5000,PC,0.5T 1 SNA
AVC08 2203-002398 C-CER,CHIP 22nF,10%,50V,X7R,1608 1 SNA
AVR73 2007-000142 R-CHIP 2.7Kohm,5%,1/16W,TP,1005 3 SNA
C 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.2m 2 SA
C 2402-001160 C-AL,SMD 330UF,20%,16V,WT,TP,1008 3 SA
C102 2203-006158 C-CER,CHIP 100nF,10%,16V,X7R,1005 84 SNA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 79 SC
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 1 SA
C151 2203-003039 C-CER,CHIP 0.008nF,0.25pF,50V,C0G,TP,100 1 SNA
C234 2203-006378 C-CER,CHIP 4700nF,10%,6.3V,X5R,TP,1608 1 SNA
C239 2203-006047 C-CER,CHIP 33nF,10%,16V,X7R,1005 6 SA
C254 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,TP,1005 13 SA
C3 2203-000384 C-CER,CHIP 0.015nF,5%,50V,C0G,1608 4 SNA
C33 2203-002687 C-CER,CHIP 1.2nF,10%,50V,X7R,TP,1005 3 SA
C510 2203-006170 C-CER,CHIP 220nF,10%,16V,X7R,1608 2 SNA
C600 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 6 SA
C637 2203-001656 C-CER,CHIP 0.47nF,5%,50V,NP0,1608 4 SNA
C802 2203-006348 C-CER,CHIP 1000nF,10%,25V,X5R,TP,1608 1 SA
CEIC1 AK09-00159A IC MICOM MC80C0316-MC015 D32,44,2.7~5.5, 1 SNA
CEQ2 0505-000110 FET-SILICON 2N7002,N,60V,115mA,7.5ohm,0. 1 SA
CER42 2007-000999 R-CHIP 510ohm,1%,1/10W,TP,1608 1 SA
CIS3 AH40-00156A TUNER TT-705FM/RDS,MAX-DG35,FM. RDS,75 o 1 SA
CON2 3722-002730 JACK-MODULAR 6P/4P,USB+LAN,ANGLE,N,AU 1 SNA
CQ3 0501-002184 TR-SMALL SIGNAL KTD1304,NPN,200mW,SOT-23 3 SA
D0254 0404-000002 DIODE-SCHOTTKY CMPSH-3,30V,100mA,SOT-23, 5 SA
D0254 0404-001006 DIODE-SCHOTTKY RB751V,40V,30mA,SOD-323,T 1 SA
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 3 SA
D1103 0406-001239 DIODE-TVS RClamp0502B,6/-/-V,125W,SOT-52 2 SA
D2505 0404-001036 DIODE-SCHOTTKY SDB30A40,40V,3000mA,SOD-1 2 SA
DC1 2203-000386 C-CER,CHIP .015nF,5%,50V,C0G,TP,1005 1 SA
DC25 2203-000812 C-CER,CHIP .033nF,5%,50V,C0G,1005 39 SA
DOIC1 AH14-10004R IC-CMOS LOGIC 74HCU04,INVERTER,SOP,14P,1 1 SNA
DR37 2007-000932 R-CHIP 470ohm,5%,1/16W,TP,1005 1 SNA
DR39 2007-000162 R-CHIP 100Kohm,5%,1/16W,TP,1005 4 SNA
DR4 2007-007142 R-CHIP 10Kohm,1%,1/16W,TP,1005 1 SNA
DS01A 0401-001049 DIODE-SWITCHING LS4148,75V,150mA,SOD-80, 1 SA
DU501 1203-001824 IC-VOL. DETECTOR 7042,SOT-89,3P,PLASTIC, 1 SA
EH01 3711-005960 HEADER-BOARD TO CABLE BOX,15P,1R,2mm,SMD 1 SA
F103 2901-001302 FILTER-EMI SMD 20V,0.3A,0pF,2.0x1.2x1.3m 3 SA
FMR4 2007-000080 R-CHIP 2Kohm,5%,1/10W,TP,1608 2 SNA
HD9 1405-001192 VARISTOR 12Vdc,30A,1.6x0.8x0.55mm,TP 29 SA
HDC11 2203-006562 C-CER,CHIP 1000nF,10%,10V,X5R,TP,1005 7 SNA
