Samsung HT-E5530 - Connecting the Optional Wireless Receiver Module

|
18 English
Connections
LANiPod WIRELESS
IMPEDANCE : 3
SPEAKERS OUT
SURROUND
SURROUND
HDM
IMPEDANCE : 3
SPEAKERS OUT
SURROUND
SURROUND
LANiPod WIRELESS
IMPEDANCE : 3
SPEAKERS OUT
SURROUND
SURROUND
HDMI OUT
IMPEDANCE : 3
SPEAKERS OUT
SURROUND
SURROUND
Front Speaker (R)
Front
Speaker (R)
Front
Speaker (L)
Subwoofer
Subwoofer
Centre Speaker
Centre Speaker
Surround Speaker (L)
Surround
Speaker (L)
Surround Speaker (R)
Surround
Speaker (R)
Front Speaker (L)
In case of HT-E5500
In case of HT-E5500
Refer to page 16 for the speakers of HT-E5530/HT-E5550.
Refer to page 16 for the speakers of HT-E5530/HT-E5550.
Connecting the Optional Wireless Receiver Module
To connect the surround speakers wirelessly, you have to purchase the wireless receiver module and TX
card from your Samsung retailer.
• This product should be connected with the SWA-5000 only.
Wireless Receiver Module
