20
SPECIFICATIONS
Model name
HW-H430
GENERAL
USB 5V/0.5A
Weight
Main unit 4.22 lbs
Subwoofer
(PS-WH450)
11.22 lbs
Dimensions
(W x H x D)
Main unit 35.7 x 1.77 x 2.75 inches
Subwoofer
(PS-WH450)
7.05 x 14.21 x 11.79 inches
Operating temperature range +41°F to +95°F
Operating humidity range 10 % to 75 %
AMPLIFIER
Rated output
power
Main unit 80W/CH, 4O
HM,
THD = 10%, 1kHz
Subwoofer
(PS-WH450)
130W, 4O
HM,
THD = 10%, 100Hz
S/N ratio (analog
input)
65 dB
Separation(1kHz) 65 dB
* S/N ratio, distortion, separation and usable sensitivity are based on measurement using AES (Audio
Engineering Society) guidelines.
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- For the power supply and Power Consumption, refer to the label attached to the product.
※ Open Source License Notice
- For further information on Open Sources used in this product, please visit the website:
http://opensource.samsung.com
- To send inquiries and requests regarding open sources, contact Samsung via Email
(oss.request@samsung.com).
appendix
HW-H430 ZC-ENG-8-21.indd 20 2014/8/27 15:15:49
