Samsung HW-S40T User Manual

ENG - 12
05 USING A WIRED CONNECTION TO THE TV
Connecting using an Optical Cable
When the audio in a broadcast is encoded in Dolby Digital and the “Digital Output Audio Format” on
your TV is set to PCM, we recommend that you change the setting to Dolby Digital. When the setting on
the TV is changed, you will experience better sound quality. (The TV menu may use different words for
Dolby Digital and PCM depending on the TV manufacturer.)
Pre-connection Checklist
• When you use an optical cable and the terminals have covers, be sure to remove the covers.
LED
Indicator
White On -> Off
“Digital Audio In”
DC 24V
SERVICE
DIGITAL AUDIO IN
(OPTICAL)
OPTICAL OUT
Bottom of the Soundbar
Optical Cable
Top of the Soundbar
1. With the TV and Soundbar turned off, connect the DIGITAL AUDIO IN (OPTICAL) port on the
Soundbar and the OPTICAL output port on the TV with the optical cable, as shown in the gure.
2. Turn on the Soundbar and TV.
3. Press the (Source) button on the top panel or remote control, and then select the “Digital
Audio In” mode.
4. The TV sound is output from the Soundbar.

Samsung HW-S40T Specifications

General

Color	black
Subwoofer	built-in
Dialogue Enhancement	no
Inputs	optical digital audio
HDMI Inputs	0
HDMI Outputs	0
HDMI 2.0 Ports	0
HDMI 2.1 Ports	0
HDMI ARC Ports	no
HDMI HDCP 2.2 Inputs	0
HDMI HDCP 2.2 Outputs	0
USB Ports	0
Bluetooth	yes
Wireless Connectivity	bluetooth
Wireless Multi-Room Audio	no
Voice Assistant	no
Remote Control	yes

Weight and Dimensions

Depth	4.5 inches
Height	2.7 inches
Width	26.8 inches
Net Weight	4.2 pounds
