4-31
4. Troubleshooting
4-3-3 Factory Data
ADC
AV Calibration
success
COMP Calibration
success
PC Calibration success
HDMI Calibration
success
ADC Target
1st_AV_Low
16 2nd_AV_Delta 2
1st_AV_High
220 2nd_COMP_R_Low 1
1st_AV_Delta 2 2nd_COMP_G_Low 1
1st_COMP_YLow 16 2nd_COMP_B_Low 1
1st_COMP_CbLow 128 2nd_COMP_High 235
1st_COMP_CrLow 128 2nd_COMP_Delta 1
1st_COMP_High 235 2st_PC_Low 1
1st_COMP_Delta 1 2st_PC_High 235
1st_PC_Low 4 2st_PC_Delta 1
1st_PC_High 235 2st_HDMI_Low 1
1st_PC_Delta 1 2st_HDMI_High 235
2nd_AV_R_Low 1 2st_HDMI_Delta 1
2nd_AV_G_Low 1
2nd_AV_B_Low 1
2nd_AV_High 235
ADC Result
1ST_Y_GH
124
1ST_Y_GL
135
1ST_Cb_BH 202
1ST_Cb_BL 184
1ST_Cr_RH 118
1ST_Cr_RL 184
2nd_R_L 113
2nd_G_L 113
2nd_B_L 113
2nd_R_H 164
2nd_G_H 164
2nd_B_H
164
