Oven
Accessories
Depending on the model that you have purchased, you are supplied
with several accessories that can be used in a variety of ways.
☛ DO NOT operate the microwave oven without the roller ring and
turntable.
Control Panel
1. Coupler, already placed over the motor shaft in the base
of the oven.
Purpose: The coupler rotates the turntable.
2. Roller ring , to be placed in the centre of the oven.
Purpose: The roller ring supports the turntable.
3. Turntable , to be placed on the roller ring with the centre
fitting to the coupler.
Purpose: The turntable serves as the main cooking
surface; it can be easily removed for cleaning.
VENTILATION HOLES
DOOR LATCHES
DOOR
TURN TABLE
COUPLER
R
O
L
L
E
R
R
I
N
G
SAFETY INTERLOCK
HOLES
LIGHT
DOOR HANDLE
TIME/WEIGHT
DIAL
VARIABLE
COOKING POWER
CONTROL KNOB
1
2
3
4
1. DISPLAY
2.
TIME/WEIGHT DIAL
3. AUTO DEFROST
4. CLOCK SETTING BUTTON
5. VARIABLE COOKING POWER
CONTROL KNOB
5
