Samsung Electronics 7-2
7-2 Main Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
M 1 DE70-30116B PANEL-OUTER;SECC,T0.6,W351.7,L1014.7,WHT-C 1 -
M 2 DE63-90035G CUSHION-RUBBER;DFA20,T2,W190,L100,BLK,-,-,- 1 PN/OUT
M 3 DE39-20054D ASSY POWER CORD;KKP-4819D/B206,250V6A,L1500 1 -
M 4 DE39-40539A WIRE HARNESS-A;230V50HZ,M935,-,-,-,- 1 -
M 5 DE91-40095A ASSY NOISE FILTER;SN-E10D(N),250V,10A,2ND-WD-TYP 1 -
M 6 DE31-30031A FAN-MOTOR;SMF745EA,230V/50HZ,ASSY-FAN-MO 1 -
M 7 DE47-20009A THERMOSTAT;PW2N-520PB,160/60,250V/7.5A,H, 1 MG-TCO
M 8 DE03-30029A MAGNETRON;OM75SH(31)ESS,-,-,-,-,- 1 -
M 9 DE93-20001A ASSY BODY LATCH;2ND-W1,M97G45/M9745,-,-,- 1 -
M10 4713-001004 LAMP-INCANDESCENT;230V,-,40W,ORG,-,-,25x71mm 1 CV/AIR
M12 DE71-60010A COVER-AIR;PP(TB53),T1.7,WHT,64G,M745,-,- 1 -
M13 DE65-20017A BUSHING CORD;IC-005,-,-,-,-,-,-,- 1 -
M14 DE66-90013A LEVER-DOOR;POM(F20-01),NTR,MW5630T,-,-,-, 1 -
M15 DE26-10121B TRANS-H.V;SHV-745EC1,230V,50HZ,KEC,2230V 1 -
M16 DE61-50106A BRACKET-HVC;SECC,T0.8,W31,L125.8,-,-,- 1 -
M17 2501-001016 C-OIL;950nF,2.1KV,BK,35x54x80,20mm 1 -
M18 DE91-70063A ASSY-HVD;V2M6,PI9.0,0.05MT,-,- 1 -
M19 DE91-70061B ASSY-H.V.FUSE;THV060T-0750-H,5KV0.75A,RED,-, 1 -
M20 DE61-40017A FOOT;PP(A353),BLK,MW5630T,-,-,- 2 -
M21 DE31-10154A MOTOR-DRIVE;M2HJ49ZR02,ST-16,21V,05ø˘ 06¿œ 1 -
M22 DE80-10003A BASE-PLATE;SGCC1-Z,T0.8,W340,L550,M745,-, 1 -
M23 DE47-20033A THERMOSTAT;PW-2N,80/70,125V15A/250V7.5A,1 1 CV-TCO
M24 DE71-60011A COVER-MGT;PP,T2.0,WHT,M745,-,-,-,-,- 1 -
M25 3601-000448 FUSE-FERRULE;250V,10A,SLOW-BLOW,CERAMIC,6.3 1 -
M26 3601-001126 FUSE-FERRULE;250V,1.6A,QUICK-ACTING,CERAMIC 1 -
M27 DE92-40165B ASSY DOOR;PUSH,WHT,M735/M745(SAW),WHT/BA 1 -
M28 DE93-30360A ASSY CONTROL-BOX;M735(SAW),-,-,-,-,-,- 1 -
M29 DE74-20102B TRAY-COOKING;GLASS,T5.0,PI288,780G,M745,-,- 1 -
M30 DE92-90436A ASSY-GUIDE ROLLER;D16.5,MW4370W,-,-,-,- 1 -
M31 DE67-60002A COUPLER;PPS,5GR,BRN,M97G45,-,-,-,- 1 -
M32 DE27-10020A COIL-MC CHOKE;TC,101 1 -
: Option Parts
: Warning
: Electrostatically Sensitive Devices
Exploded Views and Parts List
