Samsung M736 - Page 20

Ref. No Parts No. Description / Specification Q'ty Remarks
D 1 DE64-40104F DOOR-A;ABS 200G WHT M736,M746/XET 1
D 2 DE67-20151E SCREEN-DOOR;PET T0.188 W166 L305 NO-BEDA 1
D 3 DE92-50126B ASSY DOOR-E;COATING BLK CE745G 1
D 4 DE64-40008B DOOR-C;PP T1.5 W L G BLK CE745G 1
D 5 DE01-00003A FILM-DOOR;PE-FILM T0.15 W143 L265 M745 1
D 6 DE64-40006A DOOR-KEY;POM(TC3005) T2.0 12GR BLK CE945G 1
D 7 DE61-70033A SPRING-KEY;ES HSWR10 PI0.6 D6.0 L22.3 BLUIN 1
7-3 Assembly Door Parts List
Samsung Electronics 7-3
Exploded Views and Parts List
Ref. No Parts No. Description / Specification Q'ty Remarks
C 1 DE66-20010E BUTTON-PUSH;ABS (HR-0370D) WHT(W9501) 17.6G 1
C 2 DE61-70076A SPRING-BUTTON;HSWR PI0.6 1
C 3 DE64-10146A KNOB;ABS WHT 5G NEW-NEWGUAD 2
C 4 DE72-70163D CONTROL-PANEL;ABS(HR-0370U) W9501(PURE-WHT) 1
C 5 DE45-10074A TIMER-ASSY;TMFK60MTAL 220/240V-50HZ CMO-TYP 1
C 6 3501-000309 RELAY-POWER;CHP11-A240S-250V15A 240V,3750VA 1
7-4 Assembly Control Box Parts List
Ref. No Parts No. Description / Specification Q'ty Remarks
B 1 DE66-40001A LATCH-BODY;POM(F20-02) 40GR NTR 1
B 2 3405-000178 SWITCH-MICRO;250V,15A 200gf,SPST-NO 2
B 3 3405-000175 SWITCH-MICRO;250V,15A 200gf,SPST-NO 1
B 4 DE66-90001A LEVER-SWITCH;P.O.M(F20-02) 2 6 NTR 2ND-W 1
7-5 Assembly Body Latch Parts List
