Samsung M736 - Main Parts List

7-2 Main Parts List
7-2 Samsung Electronics
Ref. No. Parts No. Description/Specification Q'ty Remarks
M 1 DE70-30116B PANEL-OUTER;SECC T0.6 W351.7 L1014.7 WHT-CO 1
M 2 DE63-90035G CUSHION-RUBBER;DFA20 T2 W190 L100 BLK 1
M 3 DE39-20054D ASSY POWER CORD;KKP-4819D/B206 250V6A L1500 1
M 4 DE39-40539A ASSY WIRE HARNESS-A;230V50HZ M935 1
M 5 DE91-40095A ASSY NOISE FILTER;SN-E10D 250V 10A "2 1
M 6 DE31-30031A FAN-MOTOR;SMF745EA 230V/50HZ ASSY-FAN-MOTOR 1
M 7 DE47-20009A THERMOSTAT;CS-7SA (160/60) 187Y 250V7.5A 160 1
M 8 DE03-30029A MAGNETRON;OM75PH(31)ESS 1
M 9 DE93-20001A ASSY BODY LATCH;2ND-W1 M97G45/M9745 1
M 10 4713-001004 LAMP-INCANDESCENT;230V,-,40W,ORG,-,-,25x 1
M 12 DE71-60010A COVER-AIR;PP (TB53) T1.7 WHT 64G M745 1
M 13 DE27-10020A COIL MC CHOKE;TC 101 1
M 14 DE66-90013A LEVER-DOOR;POM(F20-01) NTR MW5630T 1
M 15 DE26-10121B TRANS-H.V;SHV-745EC1 230V 2230V/3.35V 50 1
M 16 DE61-50106A BRACKET-HVC;SECC T0.8 W31 L125.8 1
M 17 2501-001036 C-OIL;950nF,2100V,BK,35x54x85,20mm 1
M 18 DE59-40001A DIODE-H.V;HVR-1X-32B-12 1
M 19 DE91-70061B ASSY-H.V.FUSE;THV060T-0750-H 5KV/0.75A RED 1
M 20 DE61-40017A FOOT;PP(A353) BLK MW5630T 2
M 21 DE31-10154A MOTOR-DRIVE;M2HJ49ZR02,ST-16 1V 5/6 1
M 22 DE80-10003A BASE-PLATE;SGCC1-Z T0.8 W340 L550 M745 1
M 23 DE47-20033A THERMOSTAT;PN-2N 80/70 125V7.5A 187 1
M 24 DE71-60011A COVER-MGT;PP T2.0 WHT M745 1
M 25 DE61-80004A HINGE-LOWER;SCP1 T2.3 ZN-COATING M745 1
M 26 DE61-80005A HINGE-UPPER;SCP1 T2.3 ZN-COATING M745 1
M 27 ASSY DOOR;M736,M746/XET WHT S.S-BASIC 1
M 28 ASSY CONTROL-BOX;230V50HZ M736/XET WHT S.S-BASIC 1
M 29 DE74-20102B TRAY-COOKING;GLASS T5.0 PI288 780G M745 1
M 30 DE92-90436A ASSY-GUIDE ROLLER;D16.5 MW4370W 1
M 31 DE67-60002A COUPLER;PPS 5GR BRN M97G45 1
: Option Parts
: Warning
: Electrostatically Sensitive Devices
Exploded Views and Parts List
