2-2-6 Parts List of Total Exploded view3 - Application Model : MAX909/910/916
No. Code No. Description Specification Remarks
1 AH64-40471A WINDOW-DOOR,A PMMA 850-43329
2 AH64-40472A WINDOW-DOOR,B PMMA 850-43329
3 AH64-50357B DOOR-CASS,A ABS L/GRAY(G6236)
4 AH64-50358B DOOR-CASS,B ABS L/GRAY(G6236)
5 AH64-40468B DECORATION-EQ ABS L/GRAY(G6236)
6 AH64-11339A KNOB-MIC ABS D/GRAY(G3174)
7 AH64-40467C DECO-FRONT ABS D/GRAY(G3174) MIC, H/STAMPING
AH64-40467D DECO-FRONT ABS D/GRAY(G3174) H/STAMPING
8 AH64-11336B KNOB-VOLUME ABS L/GRAY(G6236)
9 AH64-40470D WINDOW-LCD PMMA 850-43329
AH64-40470E WINDOW-LCD PMMA 850-43329 RDS
10 AH64-50359C DOOR-TRAY ABS L/GRAY(G6236)
11 AH64-70003H BADGE-BRAND ABS BLK(H/STAMP)
12 AH64-30449B CABINET-FRONT MIPS L/GRAY(G6236)
13 AH61-00013A SPRING-EJECT SUS •’1.1
14 AH61-80030A DAMPER-ASSY POM BLACK
15 AH64-11337B KNOB-POWER MIPS L/GRAY(G6236)
16 AH64-11342B KNOB-DIRECTION ABS NATURAL
17 AH64-11338B KNOB-FUNCTION ABS M/GRAY(G4339)
18 AH67-10192B LENS-EQ PMMA CLR
19 AH67-40043A FILTER-TURBO PC 0.16t
20 AH64-11343B KNOB-CD ABS L/GRAY(G6236)
21 AH67-10168A LENS-JOG PMMA SMOKE RDS
22 AH64-11340A KNOB-CASS,S ABS M/GRAY(G4339)
23 AH64-11341A KNOB-CASS,L ABS M/GRAY(G4339)
24 AH64-30444A CABINET-SIDE,L MIPS L/GRAY(G6236)
25 AH64-30445A CABINET-SIDE,R MIPS L/GRAY(G6236)
26 AH64-30443A CABINET-TOP MIPS L/GRAY(G6236)
27 AH61-00021A SUPPORT-PCB ABS BLK
28 AH64-30416A CABINET-BOTTOM SECC 1.0T
29 AH64-30446B CABINET-REAR MIPS M/GRAY
AH64-30446C CABINET-REAR MIPS M/GRAY DIGITAL OUT
AH64-30446D CABINET-REAR MIPS M/GRAY SURROUND
30 AH64-11334B KNOB-EQ ABS WHT
Samsung Electronics2-10
2-2-7 Parts List of Total Exploded view4 - Application Model : MAX932/938
No. Code No. Description Specification Remarks
1 AH64-40457D WINDOW-CD PMMA VIOLET
AH64-40457E WINDOW-CD PMMA VIOLET RDS
2 AH64-70003H BADGE-BRAND AL SAMSUNG
3 AH64-50353B DOOR-CD ABS L/GRAY(G6236) ALL COMMON
4 AH64-40458E WINDOW-DOOR,CD PMMA 850-71129 MAX-932
AH64-40458M WINDOW-DOOR,CD PMMA 850-71129 MAX-938
5 AH67-40036A FILTER-VFD PC 0.3T BLK ALL COMMON
6 AH64-40459A WINDOW-VFD PMMA 850-41802 ALL COMMON
7 AH61-20535K CAP-FRONT,E MIPS D/GRAY(G3174) 932P
AH61-20535L CAP-FRONT,E MIPS D/GRAY(G3174) 932P, RDS
AH61-20536F CAP-FRONT,D MIPS D/GRAY(G3174) 932P MICÍÛ
8 AH64-11321B KNOB-VOLUME L/GRAY(G6236)
9 AH61-20538B CAP-JOG ABS NATURAL
10 AH64-40462A DECO-JOG ABS 94HB BLK
11 AH61-20537B CAP-TIMER ABS NATURAL
12 AH64-11317B KNOB-TIMER ABS NATURAL
13 AH64-40460A WINDOW-DOOR,A PMMA 850-71129
14 AH64-40461A WINDOW-DOOR,B PMMA 850-71129
15 AH64-50351B DOOR-CASS.A ABS L/GRAY(G6236)
16 AH64-50352C DOOR-CASS.B ABS L/GRAY(G6236) HIGH SPEED DUBBING
17 AH61-62004A SPRING-EJECT,A STS •’1.1
18 AH61-62005A SPRING-EJECT,B STS •’1.1
19 AH64-30441B CABINET-FRONT MIPS L/GRAY(G6236) BASIC
20 AH61-80030A ASS’Y DAMPER POM
21 AH95-500011A ASS’Y LATCH POM
22 AH67-10187A LENS-REC PMMA MILKY
23 AH64-11318A KNOB-DUBBING D/GRAY(G3174)
24 AH67-10184B LENS-TURBO ACRYL CLR
25 AH67-40038A FILTER-TURBO KIMO 100
26 AH61-20543A HOLDER-TURBO ABS WHT
27 AH64-11320B KNOB-FUNTION L/GRAY(G6236)
28 AH64-11315A KNOB-DISC L/GRAY(G3174)
29 AH64-11319A KNOB-DEMO D/GRAY(G3174)
30 AH64-11316B KNOB-POWER L/GRAY(G6236)
31 AH64-11214C KNOB-MIC D/GRAY(G3174) OPTION
32 AH61-00021A SUPPORT-PCB ABS 94HB BLK
33 AH64-30444A CABINET-SIDE,L MIPS M/GRAY
34 AH64-30445A CABINET-SIDE,R MIPS M/GRAY
35 AH62-32002A HEAT-SINK,P AL
36 AH64-30443A CABINET-TOP MIPS M/GRAY
37 AH64-30416A CABINET-BOTTOM SECC 1.0T
38 AH64-30446E CABINET-REAR MIPS M/GRAY
AH64-30446F CABINET-REAR MIPS M/GRAY RDS
39 AH61-20540A HOLDER-TUNER PC + ABS BLK
To Next Page
