2001-001107 R-CARBON(S);220ohm,5%,1/2W,AA,TP,2.4x6.4mm
2001-001192 R-CARBON(S);820ohm,5%,1/2W,AA,TP,2.4x6.4mm
AR26 2003-000468 R-METAL OXIDE(S);10ohm,5%,1W,AA,TP,3.3x9mm
AR3 2003-000468 R-METAL OXIDE(S);10ohm,5%,1W,AA,TP,3.3x9mm
2003-000587 R-METAL OXIDE(S);22ohm,5%,1W,AA,TP,3.3x9mm
DVR3 2103-000004 VR-SEMI;2Kohm,30%,1/10W,SIDE
DVR4 2103-000171 VR-SEMI;10KOHM,30%,1/10W,TOP
FC29 2201-000377 C-CERAMIC,DISC;220PF,5%,50V,UJ,TP,8.0X3.0,5
FC30 2201-000377 C-CERAMIC,DISC;220PF,5%,50V,UJ,TP,8.0X3.0,5
OC4 2201-000483 C-CERAMIC,DISC;33pF,5%,50V,CH,TP,5x3,5
RC1 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
RC2 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
FC24 2201-000557 C-CERAMIC,DISC;470pF,10%,50V,SL,TP,8x3,5
2201-000642 C-CERAMIC,DISC;680pF,10%,50V,Y5P,TP,5x3,2.5mm
AC12 2201-000653 C-CERAMIC,DISC;68pF,5%,50V,SL,TP,4.0X3.5mm,2.
AC23 2201-000653 C-CERAMIC,DISC;68pF,5%,50V,SL,TP,4.0X3.5mm,2.
AC22 2201-000674 C-CERAMIC,DISC;820PF,10%,50V,Y5P,BK,5.0X3.0,2
AC4 2201-000674 C-CERAMIC,DISC;820PF,10%,50V,Y5P,BK,5.0X3.0,2
2201-000783 C-CERAMIC,DISC;100NF,+80%,-20%,50V,Y5V,TP,8X3
2202-000644 C-CERAMIC,MLC-AXIAL;33nF,10%,50V,X7R,TP,2.5x6.6,-
DC11 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC15 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC42 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC55 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC56 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC9 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
FC46 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
FC47 2202-000781 C-CERAMIC,MLC-AXIAL:100pF,10%,50V,Y5P,TP;100PF,10%,50V,Y5P,TP,3.5X19,-
DC58 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP,3.5x19,-
DC59 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP,3.5x19,-
DC27 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
DC28 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
DC3 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
DC52 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,-
DC53 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,-
FC1 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,-
FC6 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,-
- 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
DC29 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP,3.5X19,-
DC21 2202-000847 C-CERAMIC,MLC-AXIAL;1,8NF,30%,50V,Y5S,TP,3.5X1.9
DC31 2202-000847 C-CERAMIC,MLC-AXIAL;1,8NF,30%,50V,Y5S,TP,3.5X1.9
DC20 2202-000848 C-CERAMIC,MLC-AXIAL;1.5NF,30%,50V,Y5S,TP,3.5X1.9,-
DC25 2202-000848 C-CERAMIC,MLC-AXIAL;1.5NF,30%,50V,Y5S,TP,3.5X1.9,-
DC30 2202-000848 C-CERAMIC,MLC-AXIAL;1.5NF,30%,50V,Y5S,TP,3.5X1.9,-
DC57 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,-
DC4 2301-000369 C-FILM,PEF;1.8nF,5%,50V,TP,5.5x12x3,3mm
DC44 2301-000369 C-FILM,PEF;1.8nF,5%,50V,TP,5.5x12x3,3mm
AC11 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
AC8 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
DC12 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
DC38 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC22 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC23 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC34 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC35 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC36 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
FC37 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
PC11 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
PC12 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
PC13 2301-000373 C-FILM,PEF;100NF,10%,50V,TP,11X12.5X6.5,7
DC22 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
DC56 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
FC33 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
OC3 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
DC18 2301-000390 C-FILM,PEF;15NF,10%,50V,TP,6.5X9X3.5MM,5M
DC23 2301-000390 C-FILM,PEF;15NF,10%,50V,TP,6.5X9X3.5MM,5M
DC35 2301-000390 C-FILM,PEF;15NF,10%,50V,TP,6.5X9X3.5MM,5M
DC34 2301-000396 C-FILM,PEF;18NF,5%,50V,TP,7X12X4,4MM
DC8 2301-000396 C-FILM,PEF;18NF,5%,50V,TP,7X12X4,4MM
FC10 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
FC12 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
FC13 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
FC38 2301-000419 C-FILM,PEF;27NF,10%,50V,TP,7.5X10.5X4MM,5
FC39 2301-000419 C-FILM,PEF;27NF,10%,50V,TP,7.5X10.5X4MM,5
DC17 2301-000428 C-FILM,PEF;3.9nF,5%,50V,TP,5.5x12x3,3mm
DC50 2301-000428 C-FILM,PEF;3.9nF,5%,50V,TP,5.5x12x3,3mm
PC23 2301-000449 C-FILM,PEF;47NF,10%,50V,TP,8X11X4.5MM,5MM
2301-000459 C-FILM,PEF;56NF,5%,50V,TP,9.5X12.5X5,6.5M
DC37 2301-000475 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x12x3.5,3.5
DC5 2301-000475 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x12x3.5,3.5
DC36 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC15 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC3 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC14 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
- 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
DC2 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC40 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
DC51 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
PC15 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
2401-000830 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
AC18 2401-000871 C-AL;220UF,20%,50V,GP,-,10X16MM,5MM
AC6 2401-000871 C-AL;220UF,20%,50V,GP,-,10X16MM,5MM
DC13 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC16 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC32 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC41 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC47 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC7 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC1 2401-001080 C-AL;330nF,20%,50V,GP,-,5x11,2mm
DC45 2401-001080 C-AL;330nF,20%,50V,GP,-,5x11,2mm
AC25 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
AC28 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
DC33 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
DC6 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC16 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC17 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC19 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC22 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC24 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC7 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC9 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
- 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
PC10 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
PC21 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
AC19 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
AC2 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
DC19 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
DC24 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC13 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC7 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC54 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC58 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
EC4 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
EC9 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC11 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC43 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC9 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
PC5 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
AC1 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
AC16 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
DC40 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC2 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC3 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC4 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC41 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC42 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC45 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC5 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
PC14 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
PC6 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
AC25 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
DC14 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
DC43 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC15 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC16 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC44 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
PC8 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC20 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
FC21 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
DC10 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC39 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC48 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC49 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
EC5 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC25 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC26 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC27 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC28 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC31 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC32 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
PL1 2701-000116 INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm
AL3 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
DL3 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
RF1 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
RF2 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
PQ12 AC14-12001G IC;KA78L05,T,-
AH90-30545F ASSY-PCB-FRONT;MAX910,FRONT S.N.A.
ULD1 0601-001232 LED;TR,LED,1PCS,130-260%
UIC3 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5
UR2 2003-000471 R-METAL OXIDE(S);10ohm,5%,2W,AA,TP,4x12mm
UAR2 2003-000690 R-METAL OXIDE(S);4.7ohm,5%,2W,AA,TP,4x12mm
UC1 2409-000123 C-EDL;47000UF,4UA,5.5V,-,BK,-,5MM
UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM
UVR1 3406-001022 SWITCH-ROTARY;5V,0.5mA,24Pulse/no click,12mm
UCW3 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT,
UCW2 3710-001045 CONNECTOR-SOCKET;22P,1R,1.25MM,ANGLE,SN
3710-001046 CONNECTOR-SOCKET;10P,1R,1.25MM,ANGLE,SN
LAMP1 4713-000158 LAMP-NEON;9V,75MA,0.7W,TRP,3X5.3MM,-,
LAMP2 4713-000158 LAMP-NEON;9V,75MA,0.7W,TRP,3X5.3MM,-,
LAMP3 4713-000158 LAMP-NEON;9V,75MA,0.7W,TRP,3X5.3MM,-,
R1 AC59-60060A MODULE-REMOCON;GP1U281R,SHARP,38KHZ,-,-,-,-
LCD AH07-00001A LCD;-,-,MAX900,-
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-4 Samsung Electronics
