NC50R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC54 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NL101 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL102 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL100 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
SL1 2701-000179 INDUCTOR-AXIAL;33uH,10%,4.2x9.8mm
NL300 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL301 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL302 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
AJ59-20150T DECK-CDP;CMS-300,-,-,-,-
SPK PS930E/AMF SPEAKER-SYSTEM;MAX930
**** MAX938/939/940/941 Parts List ****
AH26-80144L TRANS-POWER;EI74X52,115/230V,60/50HZ,MAX940
AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,VDE
AH59-20006B DECK-CASSETTE;ADR2113MW,MAX950,DC12V,DOUBLE
AH90-10752YASSY-PCB-TUNER;MAX900,CE+RDS BAND S.N.A.
TFL4 14529-304-610 FILTER CERAMIC;AHCM2-450BL
TX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM
TFL2 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
TWA1 3710-001421 CONNECTOR-SOCKET;14P,1R,2mm,ANGLE,SN
TJ2 3711-000814 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,ANGLE,SN
HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL
TIC1 AH14-10008B IC;LA1837,DIP,RF+MPX
TLPF1 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TLPF2 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TL2 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BULK,
TL3 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
TC39 AH61-40022A STUD-TAP;SPC1,T0.5,BT2,-,-,
RZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
RR1 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR5 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR2 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
RC9 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
RC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
RC7 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
RC8 2203-001058 C-CERAMIC,CHIP;560pF,5%,50V,NPO,2012,-,TP
RC4 2203-001524 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,2012,-
RC5 2203-001524 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,2012,-
RC1 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RX1 2801-003601 CRYSTAL-UNIT;4.332MHz,30ppm,28-AAM,30pF,
RIC1 AH14-10008E IC;BU1923F,SOP,+5V
TR19 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR24 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR43 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR48 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR50 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR53 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR56 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
TR52 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR29 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR23 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
TR4 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR17 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR37 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR6 2007-001033 R-CHIP;560OHM,5%,1/8W,DA,TP,3216
TR25 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
TR27 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
TR38 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TR44 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TC48 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
TC41 2203-000239 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,2012,-
TC20 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
TC28 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
TC29 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
TC3 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
TC44 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
TC7 2203-000429 C-CERAMIC,CHIP;18pF,5%,50V,NPO,TP,2012,-
TC1 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012,-
TC5 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012,-
TC33 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,-
TC10 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC13 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC15 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC35 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC45 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC6 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
TC61 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012,-
TC62 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012,-
TC32 2203-001132 C-CERAMIC,CHIP;680pF,5%,50V,NPO,2012,-,TP
TC2 2203-001517 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,2012,-
TC63 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
TC64 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
TC50 2203-001611 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,2012,2mm
TC51 2203-001611 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,2012,2mm
TD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TZD1 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64V,500mW
TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ7 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TR30 2001-000117 R-CARBON(S);68ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR44 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR58 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,-
TR5 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
TR39 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,-
TR57 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,-
TR55 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
TR18 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
TR3 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
TR13 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
TR16 2001-000527 R-CARBON;22ohm,5%,1/8W,AA,TP,1.8x3.2mm
TR32 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,-
TR34 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,-
TR61 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,-
TR62 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,-
TR42 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,-
TSR1 2103-000290 VR-SEMI;20Kohm,30%,1/10W,TOP
TC14 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
TC39 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
TC40 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
TC42 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
TC21 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
TC46 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
TC12 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC26 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC27 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC30 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC34 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
TC36 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
TC38 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM
TC11 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC17 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC19 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC16 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC23 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC25 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
TC18 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC43 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC4 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC9 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
AH94-10015R ASSY-PCB,CD,MANU;CMS55HK/E, S.N.A.
0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,-
2001-000522 R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
2201-000928 C-CERAMIC,DISC;2.7NF,20%,16V,Y5R,TP,3.5X1.9,-
2903-000102 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,150KHZ+-50KH
2903-000102 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,150KHZ+-50KH
3716-000210 TERMINAL-BLOCK;-,-,-,60V,7A
AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC
AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC
AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT
AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT
AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-13
