Samsung MAX-939 - Page 41

PD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
PD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
PD1 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PD2 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PD4 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PD5 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PD6 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP
EZD1 0403-000354 DIODE-ZENER;UZ5.1B,5.1V,4.8-5.4V,500mW,DO-
PZD5 0403-000354 DIODE-ZENER;UZ5.1B,5.1V,4.8-5.4V,500mW,DO-
PZD9 0403-000354 DIODE-ZENER;UZ5.1B,5.1V,4.8-5.4V,500mW,DO-
PZD4 0403-000377 DIODE-ZENER;UZP10B,10V,9.4-10.6V,1W,DO-41,
PZD6 0403-000377 DIODE-ZENER;UZP10B,10V,9.4-10.6V,1W,DO-41,
PZD7 0403-000379 DIODE-ZENER;UZP12B,12V,11.4-12.6V,1W,DO-41
PZD8 0403-000379 DIODE-ZENER;UZP12B,12V,11.4-12.6V,1W,DO-41
PZD3 0403-000396 DIODE-ZENER;UZP6.8B,6.8V,6.4-7.2V,1W,DO
PZD1 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-41
PZD2 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-41
DQ22 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
DQ7 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
DQ8 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
DQ9 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
FQ4 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
PQ3 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
PQ5 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
PQ6 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
AQ12 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
AQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
PQ10 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
PQ8 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
AQ22 0501-000296 TR-SMALL SIGNAL;KSA709-Y,PNP,800mW,TO-92,TP,12
PQ17 0501-000331 TR-SMALL SIGNAL;KSC1009-Y,NPN,800mW,TO-92,-,12
AQ19 0501-000354 TR-SMALL SIGNAL;KSC1845-F,NPN,500mW,TO-92,TP,3
AQ2 0501-000354 TR-SMALL SIGNAL;KSC1845-F,NPN,500mW,TO-92,TP,3
AQ20 0501-000354 TR-SMALL SIGNAL;KSC1845-F,NPN,500mW,TO-92,TP,3
AQ3 0501-000354 TR-SMALL SIGNAL;KSC1845-F,NPN,500mW,TO-92,TP,3
DQ5 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,-,120-
PQ4 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,-,120-
AQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
AQ16 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
DQ13 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
DQ19 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
DQ20 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
DQ21 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
DQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
EQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
AQ13 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12
AQ15 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12
AQ5 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12
AQ7 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12
DQ3 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12
DQ4 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
PQ11 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
PQ15 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
AQ14 0501-002188 TR-SMALL SIGNAL;KSA992,PNP,500mW,TO-92,TP,300-
AQ6 0501-002188 TR-SMALL SIGNAL;KSA992,PNP,500mW,TO-92,TP,300-
AQ23 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
DQ18 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
FQ7 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
FQ8 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
PQ13 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
PQ9 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
AQ21 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
DQ17 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
FQ2 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
FQ3 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
PQ18 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
DQ1 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
DQ10 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
DQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
FQ1 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
FQ5 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
FQ6 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
PQ14 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
PQ16 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP
FIC3 1001-001065 IC-ANALOG SWITCH;NJU4066BM,CMOS,DMP,14P,
FIC1 1201-000163 IC-OP AMP;BA4560F-E2
FIC2 1201-000163 IC-OP AMP;BA4560F-E2
FIC5 1201-000163 IC-OP AMP;BA4560F-E2
AR30 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR8 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
DR13 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
DR52 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
DR55 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR6 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER9 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR37 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR40 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR8 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR14 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4MM
PR22 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4MM
PR34 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR11 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR28 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR33 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR5 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
PR14 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
ER6 2001-000036 R-CARBON;330OHM,5%,1/4W,AA,TP,2.4X6.4MM
AR44 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR45 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4MM
PR25 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4MM
PR16 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR22 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR42 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR19 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR20 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR21 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR24 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR100 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR28 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
SR6 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR3 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR59 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR35 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR36 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR15 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR40 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR9 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR53 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR37 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
SR3 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR16 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR47 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR49 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
CR1 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
CR2 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
CR3 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR30 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR31 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR50 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR52 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR53 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DD7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR48 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR49 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR50 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR68 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR72 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER11 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR10 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR2 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR25 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR26 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR27 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR34 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR51 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR9 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR11 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR12 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR18 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR36 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER2 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR21 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR12 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR34 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR10 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR19 2001-000397 R-CARBON;180KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR73 2001-000397 R-CARBON;180KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR43 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR6 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER5 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR14 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR18 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR20 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR27 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR34 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR39 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR41 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR57 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR76 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR8 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
SR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR19 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR48 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR50 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR25 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR27 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR28 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR29 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-22 Samsung Electronics
