FC39 2301-000419 C-FILM,PEF;27NF,10%,50V,TP,7.5X10.5X4MM,5
DC17 2301-000428 C-FILM,PEF;3.9nF,5%,50V,TP,5.5x12x3,3mm
DC50 2301-000428 C-FILM,PEF;3.9nF,5%,50V,TP,5.5x12x3,3mm
DC25 2301-000446 C-FILM,PEF;4.7NF,5%,50V,TP,6X12X3,3.5MM
SC2 2301-000446 C-FILM,PEF;4.7NF,5%,50V,TP,6X12X3,3.5MM
PC23 2301-000449 C-FILM,PEF;47NF,10%,50V,TP,8X11X4.5MM,5MM
DC37 2301-000475 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x12x3.5,3.5
DC5 2301-000475 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x12x3.5,3.5
AC11 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
AC8 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
DC12 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
DC38 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC22 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC23 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC34 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC35 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC36 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
FC37 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
PC11 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
PC12 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
PC13 2303-000311 C-FILM,PPF;100NF,5%,100V,TP,10X13.5X4,5MM
PC3 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
DC2 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
DC36 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
OC2 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC15 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC3 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC14 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC17 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC18 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC5 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC6 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
PC4 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
FC40 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
PC6 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
DC51 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
PC15 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
EC8 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
SC1 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
DC13 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC16 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC32 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC41 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC47 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC7 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
DC1 2401-001080 C-AL;330nF,20%,50V,GP,-,5x11,2mm
DC45 2401-001080 C-AL;330nF,20%,50V,GP,-,5x11,2mm
AC25 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
AC28 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
DC33 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
DC6 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC16 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC17 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC19 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC22 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC24 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC7 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC9 2401-001538 C-AL;47UF,20%,25V,GP,-,6X11,2.5MM
PC10 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
PC21 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
AC19 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
AC2 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
DC24 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC13 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC7 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC54 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC58 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
EC4 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
EC9 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC11 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC43 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC9 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
PC4 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
PC1 2401-001943 C-AL;3300UF,20%,50V,GP,BK,25X40MM,1
AC1 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
AC16 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
DC40 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC2 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC3 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC4 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC41 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC42 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC45 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
FC5 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
PC14 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
SC3 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
SC4 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
DC14 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
DC43 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
EC6 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC15 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC16 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC44 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
PC8 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC20 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
FC21 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
FC7 2401-001994 C-AL;3.3UF,20%,50V,BP,TP,5X11MM,5
FC8 2401-001994 C-AL;3.3UF,20%,50V,BP,TP,5X11MM,5
DC10 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC39 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC48 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
DC49 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
EC5 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC25 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC26 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC27 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC28 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC31 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC32 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
PL1 2701-000116 INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm
AL3 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
DL3 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
RF1 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
RF2 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
PQ12 AC14-12001G IC;KA78L05,T,-
AH94-00070A ASSY-MANU-PRO LOGIC;MAX932P
LD5 0402-000450 DIODE-BRIDGE;PBL403,200V,4.0A,DIP-4
LIC3 1201-001026 IC-POWER AMP;7265,ZIP,11P,19.6MIL,DUAL,1000
LIC4 1204-001472 IC AUDIO PROCESSOR;M62463FP,QFP,64P,-,PL
2201-000795 C-CERAMIC,DISC;10nF,10%,400V,Y5P,TP,15x10,5
LC70 2401-001925 C-AL;2200UF,20%,25V,GP,BK,16X26,7.5
LC71 2401-001925 C-AL;2200UF,20%,25V,GP,BK,16X26,7.5
LCW3 3711-001018 CONNECTOR-HEADER;BOX,5P,1R,2mm,STRAIGHT,SN
LCW2 3711-001168 CONNECTOR-HEADER;BOX,9P,1R,2.5MM,STRAIGHT,SN
LCW1 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN
LJACK1 3722-000398 JACK-RCA;3P/2C,3.5MM,SN,BLK,#16~22
LJACK2 3722-001011 JACK-RCA;2P,3.5MM,NI,BLK,-
UIC1 AH09-00002A IC-MICOM MASKING;-,100P,-,-,-
LL1 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
LL2 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AH39-00004A LEAD CONNECTOR-ASSY;-,5264,5395,9,250,2547#26
AH39-20006G LEAD-CONNECTOR ASS’Y;51004,5295,5P,300MM,1007#26
AH59-00004A REMOCON—ASSY;-,-,-,22KEY,MAX940,-
G3VI M;CDP PACK
NQ1502 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,TP,90-
NIC928 0904-001159 IC-DSP;9286,8BIT,QFP,80P,-,1MHZ,TR,CM
NIC925 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE,-,ST,
NIC922 1204-001286 IC-ASP;KB9223,QFP,80P,-,PLASTIC,6V,20
NR109 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR203 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR300 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57L 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57R 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR606 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR602 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR603 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR104 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR107 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR100 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR120 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR121 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR204 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
FREE 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR103 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR119 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR400 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
NR115 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
NR10 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR11 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR12 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR5 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR54L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR54R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR6 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR604 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR7 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR8 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR804 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
SR3 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
SR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR114 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
NR50L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
NR50R 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
NR101 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
NR200 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR52L 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR52R 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR201 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR202 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR105 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR995 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR996 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-24 Samsung Electronics
