Samsung MAX-B450 - Speaker Exploded View for MAX-B420

Samsung Electronics 2-7
PS B420E : AH81-00639A
No. Description Specification Code No. Q'TY
1 Piezo Deco
Hips AH81-00639B
1
NET
2
AH81-00639CHips 1
Unit Woofer3 AH81-00639D5
1
/
4
"1
Cabanet4 AH81-00639EPB9t 1
* CAUSION : It is used the bonding, connet NET FRAME(or FRONT PANEL ASS’Y) to CABINET ASS’Y.
So when the disassembly, take extreme care not to demage the SPEAKER.
2-5-2 MAX-B420
