UC10 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
UC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
UC14 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC15 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC16 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC2 2401-001919 C-AL;2.2uF,20%,50V,-,TP,4x7mm,5
UC3 2401-001931 C-AL;220nF,20%,50V,-,TP,4x7mm,5
UC1 2409-000123 C-EDL;47000UF,4UA,5.5V,-,BK,-,5MM
USW1 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW10 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW11 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW12 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW13 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW14 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW15 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW17 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW18 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW19 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW2 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW20 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW21 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW22 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW23 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW24 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW25 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW26 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW27 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW29 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW3 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW30 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW31 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW32 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW33 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW34 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW35 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW4 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW5 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW6 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW7 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW8 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW9 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
UIC3 AC14-12001G IC;KA78L05,T,-
G3V1-H DECK CDP;CDP PACK S.N.A.
AH92-00005A ASSY-PCB-CD MAIN;G3VI,CD PACK
NQ1502 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,TP,90-
NIC928 0904-001442 IC-DSP;9286,8Bit,QFP,80P,-,16.9344MHz,TR,CMOS,P
NIC925 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE,-,ST,
NIC922 1204-001286 IC-ASP;KB9223,QFP,80P,-,PLASTIC,6V,20
NR109 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR203 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR300 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57L 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57R 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR606 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR602 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR603 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR104 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR107 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR100 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR120 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR121 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR204 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR103 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR119 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR13 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR400 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
NR115 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
NR10 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR11 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR12 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR5 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR54L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR54R 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR6 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR604 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR7 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR804 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
SR3 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
SR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR114 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
NR50L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
NR50R 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
NR101 2007-000593 R-CHIP;22OHM,5%,1/10W,DA,TP,2012
NR200 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR52L 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR52R 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
NR201 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR202 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR105 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR995 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR996 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR997 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR998 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR53L 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR53R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR55L 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR55R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR2 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR117 2007-000898 R-CHIP;430Kohm,5%,1/10W,DA,TP,2012
NR108 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
NR111 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
NR112 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
NR116 2007-001195 R-CHIP;820KOHM,5%,1/10W,DA,TP,2012
NR994 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
NR999 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
2007-001216 R-CHIP;82OHM,5%,1/10W,DA,TP,2012
NC107 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC108 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC119 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC120 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC121 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC600 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC901 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
NC1 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC103 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC112 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC113 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC116 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC205 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC502 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC503 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC504 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC53L 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC53R 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC602 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC800 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC804 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC905 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
SC1 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
SC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
SC6 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
NC190 2203-000335 C-CERAMIC,CHIP;0.012nF,5%,50V,NP0,TP,2012
NC190 2203-000429 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,2012
NC117 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,2012,-
NC110 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
NC118 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
NC101 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
NC111 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
NC125 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
NC100 2203-000892 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012
NC106 2203-000892 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012
NC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
NC667 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
NC115 2203-001137 C-CERAMIC,CHIP;68nF,+80-20%,50V,Y5V,TP,2012,-
NC104 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC52L 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC52R 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC603 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC903 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC102 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
NC201 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
NC202 2203-001619 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,2012
NC203 2203-001619 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,2012
NL105 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
1003-000298 IC-MOTOR DRIVER;LB1641,SIP,10P,-,-,-,ST,PLASTI
SIC1 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
SIC2 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
NXF100 2802-000211 RESONATOR-CERAMIC;16.93MHZ,0.5%,TP,10.0X5.0X10.0
SCW5 3708-001131 CONNECTOR-FPC/FC/PIC;5P,1.25mm,STRAIGHT,SN
WCW1 3708-001252 CONNECTOR-FPC/FC/PIC;16P,1mm,STRAIGHT-F,SN
SCW1 3708-001438 CONNECTOR-FPC/FC/PIC;22P,1.25mm,ANGLE,SN
NCW500 3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN
SCW7 3711-003379 CONNECTOR-HEADER;NOWALL,3P,1R,2.5mm,STRAIGHT,SN
AµA’ 3811-000121 WIRE-PVC CU;BCWA,300V,100MM,7/0.16MM,#26,B
BµB’ 3811-000121 WIRE-PVC CU;BCWA,300V,100MM,7/0.16MM,#26,B
NCW101 AH39-00060A LEAD CONNECTOR-ASSY;-,51015-08,51004-08,8P,300MM,1007#28
NCW102 AH39-20561P LEAD CONNECTOR-ASSY;-,5295,PHR,6P,150mm,1007#28
ND200 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND201 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND202 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND203 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
SZD1 0403-000352 DIODE-ZENER;UZ4.7BM,4.7V,4.4-5.0V,500mW,DO
SZD2 0403-000361 DIODE-ZENER;UZ6.2BSB,6.2V,5.99-6.24V,50
NQ1501 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
SR1 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
NR106 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR1 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR2 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR8 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR113 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR555 2008-000140 R-FUSIBLE;2.2OHM,5%,1/2W,AA,TP,3.5X9.4MM
NC400 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-35
