Samsung MH040FXEA2A - MAIN PCB(Outdoor Unit)

8-10Samsung Electronics
■ MH040FXEA2/MH052FXEA2/MH14VP2X/MH16VP2X/MH18VP2X/MH19VP2X/MH14VW2X/MH16VW2X/MH18VW2X/MH19VW2X
8-2 MAIN PCB(Outdoor Unit)
!
Compressor C/W
@
Communication
#
Display 4P
$
Display 10P
%
EEV A
^
EEV B
&
Thermistor-Out/Discharge
*
Thermistor-O.L.P Condenser
(
4 way C/W
)
Fan
1
Heater C/W
2
Earth C/W
3
Power C/W
4
Reactor C/W
*
4
1
&^ %
)
@
!
(
3
#
$
2
