E-15
ENGLISH
Connecting the Cables to the Outdoor Unit(Continued)
INSTALLING THE OUTDOOR UNIT
MH070FXEA4A / MH080FXEA4A
       
   
 
1(L) 2(N) F1  1(L) 2(N) F1 1(L) 2(N) F1 1(L) 2(N) F1




 
 
 
 
 










 
 

 
 




 




     

A B C D
A C
B D
A-unit B-unit C-unit D-unit
Indoor unit
Assembly cable
Outdoor unit
Earth
terminal
Earth
terminal
Earth
terminal
Earth
terminal
Earth
terminal
Earth
terminal
Earth
terminal
Earth
terminal
Power cable to indoor units
Earth
terminal
Main Power
supply cable
Communication cable
to indoor units
�
�
�
Cable Type: A
Cable Type: B
Cable Type:
C
Type Use AWG Cross sectional area(mm
2
)
Main Power Supply 3-wire power cable
13 or fewer 2.5 or more
Indoor Power Supply 3-wire power cable 16 or fewer 1.5 or more
2-wire assembly cable 16 or fewer 1.5 or more
�
�
�
The specification for cables :
