Samsung MH080FXEA4A - Combination Table

E-33
ENGLISH
COMBINATION TABLE
Combination Table
 Indoor unit combination 2600 & 2900 in the table below means that both  023  and  026  models can be applicable.
 Indoor unit combination 3500 & 3800 in the table below means that both 030 and 035 models can be applicable.
MH040FXEA2A ( Full Load Ampere - Cooling)
Current: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Cooling Capacity (W) Capacity
Power Consump-
tion
Current
EER EG
A B C D % Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W W W A A A
1 Unit
2000 50% 2000 2100 2100 1350 2100 2520 430 540 630 2.0 2.5 2.9 3.89
A
2600 65% 2600 2600 2600 1350 2600 3120 440 750 880 2.0 3.4 4.0 3.47 A
3500 88% 3500 3500 3500 1350 3500 4200 440 1160 1360 2.0 5.3 6.2 3.02
B
2 Unit
2000 2000 100% 4000 2000 2000 4000 1500 4000 4300 470 1200 1390 2.2 5.5 6.4 3.33
A
2000 2600 115% 4600 1761 2289 4050 1500 4050 4300 480 1180 1400 2.2 5.4 6.4 3.43
A
2000 3500 138% 5500 1491 2609 4100 1500 4100 4700 480 1220 1480 2.2 5.6 6.8 3.36
A
2600 2600 130% 5200 2050 2050 4100 1500 4100 4700 480 1220 1480 2.2 5.6 6.8 3.36
A
2600 3500 MAX 153% 6100 1748 2352 4100 1500 4100 4700 480 1220 1480 2.2 5.6 6.8 3.36 A
MH040FXEA2A (Full Load Ampere - Heating)
Conversion formula: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Heating Capacity(W) Capacity
Power Consump
-
tion
Current
EER EG
A B C D % Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W W W A A A
1 Unit
2200 47% 2200 2600 2600 1300 2600 2990 350 760 910 1.6 3.5 4.2 3.42
B
2900 62% 2900 3100 3100 1300 3100 3450 350 900 1080 1.6 4.1 4.9 3.44
B
3800 81% 3800 3800 3800 1300 3800 4370 350 1180 1420 1.6 5.4 6.5 3.22
C
2 Unit
2200 2200 94% 4400 2200 2200 4400 1500 4400 5060 380 1160 1390 1.7 5.3 6.4 3.79
A
2200 2900 109% 5100 1941 2559 4500 1500 4500 5180 380 1190 1420 1.7 5.4 6.5 3.78 A
2200 3800 128% 6000 1723 2977 4700 1500 4700 5300 380 1240 1490 1.7 5.7 6.8 3.79
A
2900 2900 123% 5800 2350 2350 4700 1500 4700 5300 380 1240 1490 1.7 5.7 6.8 3.79 A
2900 3800 MAX 143% 6700 2034 2666 4700 1500 4700 5300 380 1240 1490 1.7 5.7 6.8 3.79
A
MH052FXEA2A (Full Load Ampere - Cooling)
Conversion formula: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Cooling Capacity (W) Capacity
Power Consump-
tion
Current
EER EG
A B C D Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W W W A A A
1 Unit
2000 38% 2000 2400 2400 1470 2400 2880 520 730 970 2.4 3.3 4.4 3.29
A
2600 50% 2600 2600 2600 1470 2600 3120 520 800 990 2.4 3.7 4.5 3.25
A
3500 67% 3500 3500 3500 1470 3500 4200 530 1090 1490 2.4 5.0 6.8 3.21
A
5200 100% 5200 5200 5200 1500 5200 5820 540 1660 2030 2.5 7.6 9.3 3.13 B
2 Unit
2000 2000 77% 4000 2000 2000 4000 1500 4000 4800 550 1240 1490 2.5 5.7 6.8 3.23
A
2000 2600 88% 4600 2000 2600 4600 1500 4600 5520 550 1420 1700 2.5 6.5 7.8 3.24
A
2000 3500 106% 5500 1891 3309 5200 1500 5200 5820 550 1730 2080 2.5 7.9 9.5 3.01
B
2000 5200 138% 7200 1444 3756 5200 1500 5200 6500 550 1590 1910 2.5 7.3 8.7 3.27
A
2600 2600 100% 5200 2600 2600 5200 1500 5200 6240 560 1730 2080 2.6 7.9 9.5 3.01
B
2600 3500 117% 6100 2216 2984 5200 1500 5200 6500 560 1730 2080 2.6 7.9 9.5 3.01
B
2600 5200 MAX 150% 7800 1733 3467 5200 1500 5200 6500 560 1570 1880 2.6 7.2 8.6 3.31
A
3500 3500 135% 7000 2600 2600 5200 1500 5200 6500 560 1620 1940 2.6 7.4 8.9 3.21
A
MH052FXEA2A (Full Load Ampere - Heating)
Conversion formula: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Heating Capacity(W) Capacity
Power Consump
-
tion
Current
EER EG
A B C D Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W W W A A A
1 Unit
2200 38% 2200 2600 2600 1560 2600 2990 520 810 1010 2.4 3.7 4.6 3.21
C
2900 50% 2900 2900 2900 1500 2900 3340 520 1030 1290 2.4 4.7 5.9 2.82
D
3800 66% 3800 3800 3800 1520 3800 4370 520 1300 1620 2.4 6.0 7.4 2.92
D
5600 97% 5600 5600 5600 1960 5600 5990 530 1810 2220 2.4 8.3 10.2 3.09
D
2 Unit
2200 2200 76% 4400 2200 2200 4400 1540 4400 4750 550 1220 1390 2.5 5.6 6.4 3.61
A
2200 2900 88% 5100 2200 2900 5100 1790 5100 5460 550 1410 1610 2.5 6.5 7.4 3.62
A
2200 3800 103% 6000 2053 3547 5600 1960 5600 5990 550 1710 1950 2.5 7.8 8.9 3.27 C
2200 5600 134% 7800 1636 4164 5800 2200 5800 6800 560 1600 1830 2.6 7.3 8.4 3.63 A
2900 2900 100% 5800 2900 2900 5800 2200 5800 6500 560 1800 2060 2.6 8.2 9.4 3.22
C
2900 3800 116% 6700 2510 3290 5800 2200 5800 6800 560 1700 1940 2.6 7.8 8.9 3.41
B
2900 5600 MAX 147% 8500 1979 3821 5800 2200 5800 6800 560 1600 1830 2.6 7.3 8.4 3.63
A
3800 3800 131% 7600 2900 2900 5800 2200 5800 6800 560 1600 1890 2.6 7.3 8.7 3.63
A
