E-34
MH060FXEA3A (Full Load Ampere - Cooling)
Conversion formula: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Cooling Capacity (W) Capacity
Power Consump
-
tion
Current
EER EG
A B C D Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W SPEC W A A A
1 Unit
2000 34% 2000 2400 2400 1280 2400 2880 400 730 930 1.8 3.3 4.3 3.29
A
2600 44% 2600 2600 2600 1280 2600 3120 400 790 1010 1.8 3.6 4.6 3.29
A
3500 59% 3500 3500 3500 1280 3500 4200 400 1070 1370 1.8 4.9 6.3 3.27 A
5200 88% 5200 5200 5200 1300 5200 6240 400 1620 2060 1.8 7.4 9.4 3.21
A
2 Unit
2000 2000 68% 4000 2000 2000 4000 1300 4000 4800 420 1240 1480 1.9 5.7 6.8 3.23 A
2000 2600 78% 4600 2000 2600 4600 1300 4600 5520 420 1410 1680 1.9 6.5 7.7 3.26 A
2000 3500 93% 5500 1909 3341 5250 1300 5250 6290 420 1680 2000 1.9 7.7 9.2 3.13
B
2000 5200 122% 7200 1606 4174 5780 1380 5780 6940 430 1780 2120 2.0 8.1 9.7 3.25
A
2600 2600 88% 5200 2600 2600 5200 1300 5200 6240 420 1730 2060 1.9 7.9 9.4 3.01
B
2600 3500 103% 6100 2276 3064 5340 1300 5340 6400 430 1760 2100 2.0 8.1 9.6 3.03
B
2600 5200 132% 7800 1967 3933 5900 1380 5900 6800 430 1810 2150 2.0 8.3 9.8 3.26
A
3500 3500 119% 7000 2735 2735 5470 1300 5470 6560 440 1705 2030 2.0 7.8 9.3 3.21 A
3500 5200 147% 8700 2374 3526 5900 1380 5900 6800 440 1840 2190 2.0 8.4 10.0 3.21 A
3 Unit
2000 2000 2000 102% 6000 1773 1773 1773 5320 1500 5320 6380 440 1690 2100 2.0 7.7 9.6 3.15
B
2000 2000 2600 112% 6600 1639 1639 2131 5410 1500 5410 6490 390 1710 2120 1.8 7.8 9.7 3.16 B
2000 2000 3500 127% 7500 1573 1573 2753 5900 1500 5900 6800 440 1770 2190 2.0 8.1 10.0 3.33
A
2000 2600 2600 122% 7200 1528 1986 1986 5500 1500 5500 6600 440 1710 2130 2.0 7.8 9.7 3.22
A
2000 2600 3500 137% 8100 1457 1894 2549 5900 1500 5900 6800 440 1770 2190 2.0 8.1 10.0 3.33
A
2000 3500 3500 153% 9000 1311 2294 2294 5900 1500 5900 6800 470 1770 2190 2.2 8.1 10.0 3.33
A
2600 2600 2600 132% 7800 1967 1967 1967 5900 1500 5900 6800 450 1770 2190 2.1 8.1 10.0 3.33
A
2600 2600 3500 147% 8700 1763 1763 2374 5900 1500 5900 6800 450 1770 2190 2.1 8.1 10.0 3.33 A
MH060FXEA3A (Full Load Ampere - Heating)
Conversion formula: kW=Btu/h x 0.000293
Outdoor unit
Indoor unit combination Heating Capacity(W) Capacity
Power Consump
-
tion
Current
EER EG
A B C D Total A B C D Total
MIN NOM MAX MIN NOM MAX MIN NOM MAX
W W W W SPEC W A A A
1 Unit
2200 35% 2200 2600 2600 1350 2600 2990 380 900 1110 1.7 4.1 5.1 2.89
D
2900 46% 2900 2900 2900 1350 2900 3340 380 1030 1270 1.7 4.7 5.8 2.82
D
3800 60% 3800 3800 3800 1350 3800 4370 380 1350 1660 1.7 6.2 7.6 2.81
D
5600 89% 5600 5600 5600 1400 5600 6440 390 1820 2240 1.8 8.3 10.3 3.08
D
2 Unit
2200 2200 70% 4400 2200 2200 4400 1500 4400 5060 400 1220 1510 1.8 5.6 6.9 3.61
A
2200 2900 81% 5100 2200 2900 5100 1500 5100 5870 400 1490 1840 1.8 6.8 8.4 3.42 B
2200 3800 95% 6000 2053 3547 5600 1800 5600 6440 400 1640 2250 1.8 7.5 10.3 3.41
B
2200 5600 124% 7800 1692 4308 6000 2200 6000 6900 450 1660 2180 2.1 7.6 10.0 3.61
A
2900 2900 92% 5800 2900 2900 5800 1500 5800 6670 400 1700 2350 1.8 7.8 10.8 3.41
B
2900 3800 106% 6700 2510 3290 5800 2200 5800 6770 460 1700 2270 2.1 7.8 10.4 3.41
B
2900 5600 135% 8500 2149 4151 6300 2200 6300 7300 450 1740 2160 2.1 8.0 9.9 3.62
A
3800 3800 121% 7600 2990 2990 5980 2200 5980 6880 460 1750 2280 2.1 8.0 10.4 3.42
B
3800 5600 149% 9400 2547 3753 6300 2200 6300 7300 450 1740 2160 2.1 8.0 9.9 3.62
A
3 Unit
2200 2200 2200 105% 6600 1960 1960 1960 5880 2200 5880 6760 460 1590 2160 2.1 7.3 9.9 3.70
A
2200 2200 2900 116% 7300 1793 1793 2364 5950 2200 5950 6840 460 1610 2160 2.1 7.4 9.9 3.70 A
2200 2200 3800 130% 8200 1690 1690 2920 6300 2200 6300 7300 460 1660 2160 2.1 7.6 9.9 3.80
A
2200 2900 2900 127% 8000 1656 2182 2182 6020 2200 6020 6920 470 1590 2160 2.2 7.3 9.9 3.79
A
2200 2900 3800 141% 8900 1557 2053 2690 6300 2200 6300 7300 470 1630 2160 2.2 7.5 9.9 3.87
A
2200 3800 3800 MAX 156% 9800 1414 2443 2443 6300 2200 6300 7300 480 1560 2160 2.2 7.1 9.9 4.04
A
2900 2900 2900 138% 8700 2100 2100 2100 6300 2200 6300 7300 480 1650 2160 2.2 7.6 9.9 3.82
A
2900 2900 3800 152% 9600 1903 1903 2494 6300 2200 6300 7300 460 1590 2160 2.1 7.3 9.9 3.96
A
COMBINATION TABLE
Combination Table (Cont.)
