Disassembly and Reassembly
Samsung Electronics4-8
No Parts Procedure Remark
3 Heat Exchanger
&
Compressor
1) Release the refrigerant at first.
2) Disassemble the Inlet and Outlet Pipe by
welding.
3) Loosen the fixing screws of the
Heat Exchanger. (Use +Screw Driver.)
4) Detach the Heat Exchanger.
5) Loosen 3 nuts of the Compressor.
(Use Monkey Spanner.)
6) Detach the Compressor.
To Next Page
