Samsung ML-1640 User Manual

Service Manual
ExplodedView and Parts list
5-12
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.5-0 JC97-03248A MEA UNIT-FRAME PAPER PATH 1 SA B 1640
5.5-0 JC97-03199A MEA UNIT-FRAME PAPER PATH 1 SA B 2240
5.5-1 JC61-01161A GUIDE-M-PAPER PATH 1 SA A
5.5-2 JC66-00814A LEVER-ACTUATOR FEED SENSOR 1 SA A
5.5-3 JB61-00107A SPRING ETC-LEVER SENSOR 1 SA A
5.5-4 JC70-10232A IPR-PLATE SAW 1 SA D
5.5-5 JC63-00625A GROUND-P-VARISTOR 1 SNA A
5.5-6 JC63-00624A GROUND-P-ZENER 1 SA A
5.5-7 JC63-00623A GROUND-P-THV 1 SNA A
5.5-8 JC63-00626A GROUND-P-SAW 1 SNA A
5.5-9 JC97-02217A MEA-UNIT HOLDER PAD 1 SA A
5.5-9-1 JC61-70911A SPRING ETC-EXIT ROLL FD 2 SA A
5.5-9-2 JC69-01568A PAD-FRICTION 1 SNA B
5.5-9-3 JC61-01169A HOLDER-M-PAD 1 SA A
5.5-10 JC66-00815A LEVER-M-KICKER P/U 2 SA D
5.5-11 JC97-02179A MEA UNIT-PICK UP GEAR 1 SA A
5.5-11-1 JC66-00803A GEAR-PICK_UP B 1 SA A
5.5-11-2 JC66-00802A GEAR-PICK_UP A 1 SA A
5.5-11-3 6107-001167 SPRING-CS 1 SA D
5.5-12 JC33-00028B SOLENOID-MP 1 SA A
5.5-13 JC66-00809A GEAR-FEED 35/19 1 SA A
5.5-14 JC61-00588A BUSH-M-TR L 1 SA A
5.5-15 JC72-00102A PMO-BUSHING_TR(L) 1 SA A
5.5-16 JC61-70940A SPRING ETC-TR(12) 2 SA A
5.5-17 JC66-00725A ROLLER-TRANSFER 1 SA A
5.5-18 JC61-00583A HOLDER-PTL 1 SA A
5.5-19 JC70-00307A IPR-P-EARTH TRANSFER 1 SA A
5.5-20 JC66-00829A SHAFT-P-PICK_UP 1 SA B
5.5-21 JC61-01151A HOUSING-M-PICK_U 1 SA A
5.5-22 JC61-01173A HOUSING-M-PICK_UP B 1 SA A
5.5-23 JC73-00211A RUBBER-PICK_UP 1 SA A
5.5-24 JC66-01935A CAM-PICKUP L 1 SA B
5.5-25 JC66-01936A CAM-PICKUP R 1 SA B
5.5-26 JC66-00813A GEAR-TRANSFER 1 SA A
5.5-27 JC61-01281A BRACKET-P-BAR_PICK_UP 1 SNA A
5.5-28 JC39-00482A CBF HARNESS-MICRO SW 1 SA A
5.5-29 JC61-01548A HOLDER-M-CAM 1 SNA A 2240
Paper Path Parts List
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”

Samsung ML-1640 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	8 MB
Processor frequency	150 MHz
Sound pressure level (printing)	50 dB
Total input capacity	150 sheets
Total output capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 2000/ XP/ 2003 Server/ Vista Linux OS Mac OS X 10.3 - 10.5
Maximum duty cycle	5000 pages per month

Weight and Dimensions

Weight	5700 g
Dimensions (WxDxH)	353 x 298 x 209 mm
