Samsung ML-1640 User Manual

1. Precautions
1.1 Safety Warning 1-1
1.2 Caution for safety
1-2
1.3 ESD Precautions
1-4
2. Product spec and feature
2.1 Product Specifications 2-1
2.1.1 Product Overview
2-1
2.1.2 Specifications
2-1
2.1.3 Model Comparison Table
2-5
2.1.4 Accessory List
2-5
2.2 System Overview
2-6
2.2.1 System Outline
2-6
2.2.2 H/W Structure and Descriptions
2-12
2.2.3 S/W Structure and Descriptions
2-25
2.2.4 Initial Product Installation
2-29
3. Disassembly and Reassembly
3.1 General Precautions on Disassembly 3-1
3.2 Disassembly and Reassembly
3-2
3.2.1 Front Cover
3-2
3.2.2 Main Cover
3-3
3.2.3 Fuser unit
3-4
3.2.4 SMPS board
3-5
3.2.5 Main PBA
3-5
3.2.6 Drive unit
3-6
3.2.7 LSU
3-7
Contents

Samsung ML-1640 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	8 MB
Processor frequency	150 MHz
Sound pressure level (printing)	50 dB
Total input capacity	150 sheets
Total output capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 2000/ XP/ 2003 Server/ Vista Linux OS Mac OS X 10.3 - 10.5
Maximum duty cycle	5000 pages per month

Weight and Dimensions

Weight	5700 g
Dimensions (WxDxH)	353 x 298 x 209 mm
