Specifications
General
Weight (MX-E630/E631/E650/E651)
2.3 Kg
Weight (MX-E660/E661)
2.7 Kg
Dimensions
203 (W) x 306 (H) x 280 (D) mm
Operating Temperature Range
+5°C~+35°C
Operating Humidity Range
10 % to 75 %
FM Tuner
Signal/noise ratio
55 dB
Usable sensitivity
12 dB
Total harmonic distortion
0.6 %
AM Tuner
(optional)
Signal/noise ratio
35 dB
Usable sensitivity
58 dB
Total harmonic distortion
1.5 %
CD Disc CD : 12 cm (COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
Amplifier
MX-E630/E631- 160 Watts (MAX. THD)
Front speaker output
80 W/CH (4 Ω/100 Hz)
MX-E650/E651- 260 Watts (MAX. THD)
Front speaker output
80 W/CH (4 Ω/100 Hz)
Subwoofer
100 W (4 Ω/100 Hz)
MX-E660/E661- 350 Watts (MAX. THD)
Front speaker output
175 W/CH (4 Ω/100 Hz)
Frequency range
20 Hz~20 KHz
MX-E630/E631/
E650/E651
S/N Ratio 80 dB
Channel
separation
65 dB
MX-E660/E661
S/N Ratio 75 dB
Channel
separation
50 dB
Input sensitivity (AUX) 800 mV
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- Design and specifications are subject to change without prior notice.
- For information on the power supply and power consumption, refer to the label attached to the product.
