Samsung NP300E5C Series 3 15.6" Notebook User Manual

54
Chapter 3.
Using the computer
Connecting to the monitor port (Optional)
You can experience a wider screen by connecting the computer to
a monitor, TV or projector with a monitor port.
You can give better presentations by connecting the computer to
a projector.
1
Connect the D-SUB port of the computer and the port of the
monitor or TV with the monitor cable (15 pin).
External
Monitor
TV
Projector
2
Connect the power cord of the connected monitor, TV or
projector and turn the power on.
Change your TV to external device mode when connecting to
the TV.
3
Press the + key once to display a window to select
the monitor mode. Select a mode.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
PC Screen only
The contents are only displayed on the PC
monitor (current device).
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Duplicate
The contents of the current device are displayed
on the external device as well.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Extend
The screen of the current device is expanded to
the external device.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Second screen Only
The contents are displayed only on the screen of
the external device.
Alternatively, to set up dual view:
Open the Display Settings window in the Control Panel,
select Monitor 2 and select the Expand to t to this
monitor checkbox to set dual view. For more detailed
information, refer to the Windows online help.
Connecting an External Display Device

Samsung NP300E5C Series 3 15.6" Notebook Specifications

General

Display Size	15.6 inches
Display Resolution	1366 x 768
Optical Drive	DVD Super Multi
Wireless	802.11 b/g/n
LAN	10/100/1000 Gigabit Ethernet
Bluetooth	Bluetooth 4.0
Processor	Intel Core i5-3210M
RAM	4 GB
Storage	500GB HDD
Graphics	Intel HD Graphics 4000
Operating System	Windows 8
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, VGA, RJ-45, Headphone output, Microphone input
Card Reader	SD, SDHC, SDXC
Battery	6-cell
Weight	2.3 kg
Dimensions	367.9 x 242.9 x 29 ~ 34.9 mm (14.48 x 9.56 x 1.14 ~ 1.37 inch)
