Chapter 3.
Using the computer
Connecting through the HDMI port (Optional)
By connecting the computer to a TV with a HDMI port, you can
enjoy both a high visual quality and a high sound quality.
After connecting a TV through HDMI, you have to congure the
screen and sound.
1
Connect the HDMI cable to the HDMI port of the TV.
External
Monitor
TV
Projector
This is only supported for models that support a TV output •
port (HDMI).
When a TV provides more than one HDMI port, connect •
the computer to the DVI IN port.
When connecting the computer to a TV, switch the •
external input mode of the TV to HDMI.
2
Press the + key once to display a window to select
the monitor mode. Select a mode.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
PC Screen only
The contents are only displayed on the PC
monitor (current device).
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Duplicate
The contents of the current device are displayed
on the external device as well.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Extend
The screen of the current device is expanded to
the external device.
3&୘ִփ
ـࢿ
୙ࢠ
ѿء୘ִփ
Second screen Only
The contents are displayed only on the screen of
the external device.
External Monitor / TV is not supported in the DOS •
Command Prompt window.
Simultaneous output to all 3 (LCD + CRT + HDMI) is not •
supported.
Connecting an External Display Device

Samsung NP300E5C Series 3 15.6" Notebook Specifications

General

Display Size	15.6 inches
Display Resolution	1366 x 768
Optical Drive	DVD Super Multi
Wireless	802.11 b/g/n
LAN	10/100/1000 Gigabit Ethernet
Bluetooth	Bluetooth 4.0
Processor	Intel Core i5-3210M
RAM	4 GB
Storage	500GB HDD
Graphics	Intel HD Graphics 4000
Operating System	Windows 8
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, VGA, RJ-45, Headphone output, Microphone input
Card Reader	SD, SDHC, SDXC
Battery	6-cell
Weight	2.3 kg
Dimensions	367.9 x 242.9 x 29 ~ 34.9 mm (14.48 x 9.56 x 1.14 ~ 1.37 inch)
