Before connecting cables
Unfasten the screws, then remove the cover.
2
thickness for each:
7 Ø hole x 1: Insert the 7
5.5 Ø hole x : Insert the 5.5
3 Ø hole x 2: Insert the 3
8.5 Ø hole x 1: Insert the 8.5
3
the marked area to ensure it is not lost.
4
5
6
Close the cover, then fasten the screws.
sure to close the cover and fasten the
screws to ensure it is water tight.
Recommended torque :10 - 12 kgf.cm
