Samsung P1401 - Page 16

SAMSUNG ELECTRONICS CO., LTD 13
8-1. WB : ASSY-PCB Part List
NO. Part Code Code No. Q'ty Description Specificatio Remark
1 WB002 1401-001007 1 THYRISTOR-TRIAC 10A,SM10LZ47(TOSHIBA) TRIAC1
2 WB002 1401-001024 5 THYRISTOR-TRIAC 2A,SM2LZ47(TOSHIBA) TRIAC 2~6
3 WB003 0402-001023 1 DIODE-BRIDGE RBV1506,600V,15A,SIP-4 BD1
4 WB004 3501-001180 1 RELAY-MINIATURE 12V DC,RTE24012 RELAY3
5 WB004 3501-001156 2 RELAY-POWER 12VDC,0.53W,16000MA,1FORMA RELAY 5
6 WB004 3501-001157 3 RELAY-POWER 12VDC,0.53W,16000MA,1FORMC RELAY 1,2
7 WB004 3501-001007 1 RELAY 12Vdc,200mW,5A,(TAKAMISAYA) RELAY6
8 WA010 DC26-00005B 1 TRANS-FORMER 450MA,220~240VAC,11VDC TRANS
9 WB003 0402-000137 6 DIODE-RECTIFIER 1N4007,1000V,1A
D15~D19
10 WB006 0504-000130 2 TR-DIGITAL KSR1105 TR3,TR4
11 WB006 DE13-20016A 1 IC-VOLT REGU. KA7805A TR7
12 WB006 0504-000159 2 TR-DIGITAL KSR2105 TR1,TR2
13 WB006 0501-000465 1 TR-SMALL MMBT390X TR5,TR6
14 WB007 1202-000141 1 IC-VOL. COMP 7033,SOT-89 IC4
15 WB008 2802-001058 1 RESONATOR-CERAMIC 8MHz,0.2%,TP,10x5x8mm RESO
16 WB007 DE13-20017A 3 IC-DRIVE KID65003AP,DIP,16P,STICK IC3,IC5,IC6
17 WB007 1103-001160 1 IC-EEPROM 4C010,128X8BIT,DIP,8P IC2
18 WB009 DE30-20016A 1 BUZZER CBE2220BA,STICK BZ
19 WB010 3404-001022 7 SWITCH-TACT 15V,20mA,130°
± 40gf,6x6x5mm SW 1~7
20 WB011 DE07-20040A * LED LAMP SLH-34VC70F,RED,T,PI5
21 WB012 0703-001056 1 LED DISPLAY Y-GRN,4dig,7seg,46X19X24.6mm
