20
SAMSUNG ELECTRONICS CO., LTD
12-1. WD : ASSY-TUB - Parts List
No. Location No. Description Code No. Q'ty P801 P1001 P1201 P1401
1 WDD01 ASSY-WIRE DIAPHRAGM DC91-12078A 1 ●● ● ●
2 WDD02 DOOR-DIAPHRAGM DC61-20219A 1 ●● ● ●
3 WDD03 ASSY-CLAMP DIAPHGRAM DC97-00850A 1 ●● ● ●
4 WDD04 BOLT-W.MOTOR DC60-40138A 3 ●● ● ●
5 WZ008 WASHER-PLAIN DC60-60044B 6 ●● ● ●
6 WZ009 WASHER-NYLON DC60-60040A 3 ●● ● ●
7 WDD05 WEIGHT-BALANCER(L) DC66-60154A 1 ●● ● ●
8 WZ010 BAND RING DC65-60125A 1 ●● ● ●
9 WDD06 HOSE-DRAWER TUB DC62-10305A 1 ●● ● ●
10 WZ011 BOLT-HEX DC60-40140A 2 ●● ● ●
11 WZ012 BOLT-FLANGE DC60-40132B 1 ●● ● ●
12 WD007 HOSE-AIR DC62-10303A 1 ●● ● ●
13 WDD07 WEIGHT-BALANCER(U) DC66-60153A 1 ●● ● ●
14 WD006 PULLEY DC66-10176B 1 ●● ● ●
15 WZ014 WASHER-SPRING DC60-60049A 1 ●● ● ●
16 WZ013 NUT-HEX DC60-50148B 1 ●● ● ●
17 WD008 BELT-TRANSMISSION DC66-10139B 1 ●● ● ●
18 WDD08 CUSHION-MOTOR DC61-00041A 1 ●● ● ●
19 WDD09 MOTOR-DRUM DC31-00002C 1 ●● ● ●
20 WZ013 BRACKET-NUT DC61-00201A 1 ●● ● ●
21 WZ010 BAND RING DC65-60118F 1 ●● ● ●
22 WDD10 HOSE-FILTER TUB DC62-10304A 1 ●● ● ●
23 WZ015 CLAMP-HOSE DC61-60497A 1 ●● ● ●
24 WDD11 PACKING-TRAP DC62-40184A 1 ●● ● ●
25 WD009 CAP-TRAP DC61-10676A 1 ●● ● ●
26 WDD12 HEATER DC47-00001A 1 ●● ● ●
27 WDD13 TUB-FRONT DC61-30346A 1 ●● ● ●
28 WDD14 BRACKET-NUT DC61-40348B 5 ●● ● ●
29 WDD15 BRACKET-HEATER DC61-40344A 1 ●● ● ●
30 WDD16 SPACER-HEATER DC61-60496A 2 ●● ● ●
31 WDD17 VANE-CHECK DC62-20311A 1 ●● ● ●
32 WDD18 ASSY-DRUM DC97-00785A 1 ● ---
DC91-12281A 1 - ● --
DC97-00785B 1 - - ●●
33 WDD19 PACKING-TUB DC62-40183A 1 ●● ● ●
34 WDD20 CLIP-TUB DC61-60499B 8 ●● ● ●
35 WDD21 ASSY-TUB BACK DC97-00214K 1 ● ---
DC97-00214B 1 - ● --
DC97-00214A 1 - - ●●
36 WDD20 CLIP-TUB DC61-60520A 1 ●● ● ●
