Samsung PG83R - Detailed Parts Listings


7-2 Main Parts List
No. Code No. Description Specification Q’ty Remark
MB01 DE96-00120B ASSY BODY LATCH M1717N,NC2000(HANDLE) 1
MB02 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1
MB03 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2
MB041 DE66-00093A LEVER-SWITCH(A) NC2000,PP-TH53,-,-,-,-,N 1
MB042 DE66-00094A LEVER-SWITCH(B) NC2000,PP-TH53,-,-,-,-,N 1
MB05 DE72-00137A LATCH-BODY NC2000(0.6/0.8/1.2),PP,-,-,-, 1
MM01 DE70-00184P PANEL-OUTER MW850WA,C/STEEL,T0.5,-,-,-,P 1
MM03 DE39-00300A WIRE HARNESS-A PG83,230V50HZ,EUROPE POWE 1
MM05 DE96-00011A ASSY NOISE FILTER SN-3WUA,120V15A,3W 15A 1
MM06 DE96-00070D ASSY-MOTOR FAN SMF-2N2PG,230V50HZ,2450RP 1
MM07 DE39-20058C ASSY POWER CORD KKP-4819D/B232,250V16A,L 1
MM08 OM75P(31)ERHT ASSY-MAGNETRON OM75P(31)ERHT 1
MM09 DE71-60457B COVER-AIR 3RD-0.7(BTM),PP,-,-,-,-,-,- 1
MM10 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1 CV/AIR
MM100 DE61-00381A SPIT-HEATER PG81/83,STS304,PI5.0,-,- 1
MM109 DE61-00356A STOPPER-HEATER PG81/83,SECC,T0.8,-,-,-,- 1 L-HEA.
MM109 DE74-80062A STOPPER-HEATER 3RD-W,SECC,T0.8xW70xL70,- 1
MM14 DE26-00080B TRANS H.V SHV-EURO2,230V,50HZ,2340V/3.5V 1
MM16 DE71-00159A COVER-CEILING CN2835,MICA SHEET,T0.3,W11 1
MM17 DE47-00002B THERMOSTAT PW2N,-,-,100,110,-,-,-,187H,3 1 GRL-TCO
MM17 DE47-20010A THERMOSTAT PW-2N(120/60)187Y,250V7.5A,12 1 CAV-TCO
MM17 DE47-20009A THERMOSTAT PW2N-520PB,160/60,250V/7.5A,H 1
MM18 DE74-20102D TRAY-COOKING GLASS,T6,-,890g 1
MM19 DE97-00193B ASSY-GUIDE ROLLER NC2000 0.6,T2*P1198(14 1
MM20 DE67-00140A COUPLER NC2000(0.6~0.8),PPS(ESS840),-,3G 1
MM22 DE31-10154A MOTOR SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 1
MM25 DE65-20014A CABLE CLAMP -,-,-,NY-66,-,DA-6N 1 P-CORD
MM27 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2
MM28 DE80-00023A BASE-PLATE MW850WA,SGCC1,T0.6,-,-,NC2000 1
MM29 2501-001011 C-OIL 910nF,2100V,BK,54x35x75mm,20mm 1
MM30 DE61-00139A BRACKET-HVC NC2000,SECC,T0.8,-,-,-,0.6/0 1
MM31 DE59-00002A DIODE-H.V ESJC13-12B,12KV,-,-,-,MWO ALL, 1
MM32 DE91-70061C ASSY-H.V.FUSE THV060T-0700-H,5KV/0.70A,B 1
MM42 DE96-00201A ASSY-WIRE HARNESS-B PG83,230V50HZ,SUPPER 1
MM55 3601-001197 FUSE-CARTRIDGE 250V,15A,SLOW-BLOW,CERAMI 1
MM57 DE61-50576A BRACKET-HEATER -,STS430,T0.5,W70,L70,-,- 2
MM59 DE71-60298A COVER-BACK -,SECC,T0.6,W273,L633,-,M6Q45 1
MM60 DE63-20017A GASKET-HEATER -,BRASS,T1.5,OD30.5,ID22.5 2
MM61 DE47-00004A HEATER-GRILL SHG-2733E,-,-,1100W(1080W), 1
MM61 DE47-00029A HEATER SHG-EPG83A,-,-,750W,-,230V50HZ,-, 1
MM62 DE61-70060A SPRING-PLATE -,SK-5,T0.5,T0.5,-,-,-,-,-, 2
MM63 DE61-30008A SUPPORT-HEATER ALUMINA,-,T12,CE745G,-, 1
MM63 DE61-00387A SUPPORT-HEATER PG81/83,ALUMINA,-,-,-,-,0 1 L/HEA.
MM64 DE97-00301A ASSY-WIRE RACK PG81/83,85MM,-,- 1
MM66 DE61-00386A BRACKET-AIR GUIDE PG81/83,SECC,T0.5,W118 1
MM67 DE61-00143A BRACKET-UPPER MW850WA,SECC,T0.5,-,-,-,NC 1
MM71 DE61-50490A BRACKET-TCO -,SECC1,T0.6,34,58,-,- 1
MM88 DE73-90027B FERRITE RU65(RU15*28.6*6.5),-,M2L(FE2O3+ 1
