Samsung PG83R - PCB Components and Diagrams; Printed Circuit Board Parts List


8-2P.C.BPartsList
Code No. Description Specification Q’ty Remark
3501-001062 RELAY-POWER 24VDC,523.2mW,16A,1FormA,15mS, 1 RY03
3501-001068 RELAY-POWER 24Vdc,523mW,16A,1FormA,15mS,10 2 RY07,RY08
3501-001155 RELAY-MINIATURE 24VDC,200MW,3000MA,1FORMA,10MS,10MS 2 RY01,RY02
3601-001126 FUSE-CARTRIDGE 250V,1.6A,FAST-ACTING,CERAMIC,5x20mm 1 FUSE
3708-001551 CONNECTOR-FPC/FFC/PIC 14P,1.25mm,STRAIGHT,SN 1 CN04
DE07-00037T LED DISPLAY CSE-4246G-18,TBMO(RUSSIA) 1 LED1
DE09-00054A IC MICOM TPM87CH47U,OTP-16K,QFP,-,-,-,- 1 IC01
DE26-00078A TRANS-L.V SLV-C100,230V,50HZ,AC17.0 1 LVT1
DE30-20016A BUZZER CBE2220BA,STICK,-,-,-,-,-,-,- 1 BUZ1
DE47-40024A HOLDER-FUSE FH-51H,7.5A,-,-,-,-,- 1 FUSE
0401-001083 DIODE-SWITCHING MM4148,100V,150MA,LL-34,TP 8 D04~D09,D13,D14
0401-001083 DIODE-SWITCHING MM4148,100V,150MA,LL-34,TP 8 D16~D23
0402-001080 DIODE-RECTIFIER GF1G,400V,1A,DO-214BA,TP 3 D01,D02,D03
0402-001298 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1 BD01
0403-001288 DIODE-ZENER ZMM55C5V1,4.8-5.4V,500MW,LL-34,TP 1 ZD01
0501-000465 TR-SMALL SIGNAL MMBT3904,NPN,350MW,SOT-23,TP,30-300 1 TR01
0504-001080 TR-DIGITAL KRC246S,NPN,200mW,2.2K/10K,SOT-23,TP 6 TR02,TR03,TR07~TR10
1202-000141 IC-VOLTAGE COMP. 7033,SOT-89,3P,-,SINGLE,0V,-,P 1 IC03
1203-001037 IC-VOLTAGE REGULATOR 78L05,SOT-89,3P,185MIL,PLASTIC 1 IC02
1404-000230 THERMISTOR-PTC 27ohm,20%,-,265V,1.5A,360mA,BK 2 PTC1,PTC2
2007-000033 R-CHIP 0OHM,5%,1/8W,DA,TP,3216 11 J01~J11
2007-000277 R-CHIP 100KOHM,1%,1/10W,DA,TP,2012 1 R13
2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 6 R07~R09,R16~R18
2007-000468 R-CHIP 1KOHM,5%,1/10W,DA,TP,2012 5 R01,R03,R04,R05,R10
2007-000468 R-CHIP 1KOHM,5%,1/10W,DA,TP,2012 10 R14,R15,R24~R31
2007-000671 R-CHIP 2KOHM,5%,1/10W,DA,TP,2012 2 R02,R11
2007-000868 R-CHIP 4.7KOHM,1%,1/10W,DA,TP,2012 1 R12
2007-000931 R-CHIP 470OHM,5%,1/10W,DA,TP,2012 1 R06
2007-000941 R-CHIP 47KOHM,5%,1/10W,DA,TP,2012 5 R19~R23
2203-000444 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,2012,- 5 C12~C16
2203-000555 C-CERAMIC,CHIP 0.02nF,5%,50V,NP0,TP,2012 2 C17,C18
2203-001608 C-CERAMIC,CHIP 22nF,+80-20%,50V,Y5V,TP,2012 4 C08~C11
2401-000151 C-AL 1000uF,20%,25V,GP,TP,10x20,5 1 C02
2401-000244 C-AL 100uF,20%,10V,GP,TP,6.3x7,5 1 C03
2401-000911 C-AL 22uF,20%,16V,GP,TP,5x7,5 2 C04,C06
2401-001428 C-AL 470uF,20%,50V,GP,TP,10x20,5 1 C01
2401-002075 C-AL 4.7uF,20%,50V,GP,TP,5x11,5 1 C05
2801-003933 CRYSTAL-UNIT 8MHz,50ppm,28-AAA,12pF,70ohm,TP 1 XTL1
3711-000881 CONNECTOR-HEADER BOX,3P,1R,2.5mm,STRAIGHT,SN 1 CN02
3711-004200 CONNECTOR-HEADER BOX,5P/7P,1R,2.5MM,STRAIGHT,SN 1 CN05
DE60-60012A PIN-EYELET ID2.1,OD2.5,L3.0,SN,BSP,T0.25, 2 -
