1. Remove 1 screw at the lower
part of the Freezer.
2. Separate the Cap.
3. Separate the Housing.
21
DISASSEMBLY AND REASSEMBLY
3-4) Freezer Door Switch
Freezer
Door Switch
Part Name How To Do Descriptive Picture
Freezer
Door
Part Name How To Do Descriptive Picture
2. Remove 4 hex head bolts from
both sides with a socket
wrench(7/16”).
3. Lift up the freezer door from the
rails.
Be careful not to drop and
scratch the freezer door.
To Next Page
