24
DISASSEMBLY AND REASSEMBLY
3-9) Gallon Door Bin
Door Bin
Part Name How To Do Descriptive Picture
1. Simply lift the bin up and pull
straight out.
(Refer to the picture)
3-10) Evaporator In Refrigerator
Evaporator In
Refrigerator
Part Name How To Do Descriptive Picture
1. Remove the screw cap with a
flat-blade screwdriver.
2. Unscrew a screw.
3. Unscrew two screws. And
remove the hook by pulling it
from the lower part and pushing
the cover down. (Refer to the
picture)
To Next Page
